Figure 1-3
5340 Appliance rear panel riser assembly locations and PCIe
slot number assignments
8
7
3
2
1
6
5
4
Riser
Assembly 3
Riser
Assembly 2
Riser
Assembly 1
The 5340 Appliance supports multiple PCIe-based I/O configurations. The following
table shows the standard I/O configurations that are available with a 5340 Appliance.
Note: A 5340 Appliance high availability (HA) configuration must use two identical
5340 compute nodes with regard to model number and hardware configuration.
For example, you can use two 5340 compute nodes with configuration D. However,
you cannot use one 5340 Appliance compute node with configuration D and one
5340 Appliance compute node with configuration B.
This requirement applies to all of the I/O configurations for each model.
Table 1-10
Available 5340 Appliance PCIe-based I/O configurations
Slot
8
Slot
7
Slot
6
Slot
5
Slot
4 *
Slot
3
Slot
2
Slot
1 *
I/O
configuration
option
QLogic
QLE8442
10GbE NIC
1, 3
(iSCSI
capable)
ReservedQLogic
QLE8442
10GbE NIC
1, 3
(iSCSI
capable)
QLogic
QLE8442
10GbE
NIC
1, 3
(iSCSI
capable)
QLogic
QLE2692
16Gb FC
HBA
3
QLogic
QLE8442
10GbE NIC
1, 3
(iSCSI
capable)
QLogic
QLE8442
10GbE
NIC
1, 3
(iSCSI
capable)
QLogic
QLE2692
16Gb FC
HBA
3
A
†
QLogic
QLE8442
10GbE NIC
1, 3
(iSCSI
capable)
ReservedQLogic
QLE2562
8Gb FC
HBA
3
QLogic
QLE8442
10GbE
NIC
1, 3
(iSCSI
capable)
QLogic
QLE2692
16Gb FC
HBA
3
QLogic
QLE8442
10GbE NIC
1, 3
(iSCSI
capable)
QLogic
QLE8442
10GbE
NIC
1, 3
(iSCSI
capable)
QLogic
QLE2692
16Gb FC
HBA
3
B
††
25Introducing Fibre Channel support on NetBackup Appliance
Supported data transfer methods for NetBackup appliances
