Table 2-6
Summary of supported NetBackup 5240 FC options (continued)
Supported options and required port configurationFC HBA slot
Port 1
■ SAN Client - target
■ Tape out - initiator
■ NetBackup for VMware - initiator
Port 2
■ SAN Client - target
Note: If Port 1 is in the initiator mode, Port 2 cannot be set to the
target mode. Port 2 can only be configured for the target mode when
the 4 target port Fibre Channel connection option is selected.
■ Optimized duplication - initiator
■ Auto Image Replication - initiator
■ Tape out - initiator
■ NetBackup for VMware - initiator
Use only one option on each port.
This slot is populated with an FC card on 5240 HBA configurations B,
C, D, E, F, G, H, K, and L.
This slot is reserved for FTMS on 5240 HBA configurations D, E, H,
and K. If you enable SAN Client FTMS with those two HBA
configurations, Port 1 is changed to target mode for SAN Client by
default.
Slot 6
See “About NetBackup SAN Client and Fibre Transport” on page 9.
See “About Fibre Transport for optimized duplication and Auto Image Replication
between appliances” on page 11.
See “How to determine appliance HBA WWPNs” on page 51.
See “About Fibre Transport paths for NetBackup appliances” on page 27.
See “Supported Fibre Channel port configurations for the NetBackup 5220 and
5230 appliances” on page 37.
See “Supported Fibre Channel port configurations for the NetBackup 53xx
appliances” on page 47.
46About the HBA port mode configuration
Supported Fibre Channel port configuration for the NetBackup 5240 appliances
