Verizon ASK-MAE340 User Manual


Interfaces & buttons
Interfaces Description
Data The “Data” port on the MoCA Ethernet Adapter is for connection
to your existing Coaxial network.
DC Port Connect the supplied 12V, 1A power adapter to this port to power
on the device.
Reset If you experience difficulties with your device or want to revert all
settings that you have changed, the reset button allows you to
reset the device back to its factory default state. A single quick
press and release the reset button restart the device. Press and
hold the reset button for 10 seconds to restore the factory default
settings.
2.5G RJ-45 Port The 2.5G RJ-45 port creates an interface to connect an Ethernet
device via your MoCA network.
1G RJ-45 Port The 1G RJ-45 ports provide 1Gbps Ethernet connection for
Ethernet enabled devices via your MoCA network.
LEDs
The LEDs indicate the system and Ethernet connection status of the MoCA Ethernet Adapter.
Indicator/ Scenario Description Light type
System System off Off
Power on Yellow
MoCA network connected White
MoCA traffic Blinking White
RJ45 10/100M connection speed Yellow
1G/2.5G connection speed White
10/100M connect (traffic) Blinking Yellow
1G/2.5G connect (traffic) Blinking White
2

Verizon ASK-MAE340 Specifications

General

General	ASK-MAE340
Certificates	FCC, UL, MoCA 2.5 Certificate
MoCA Standard	MoCA 2.5
Coax in Frequency	Extended D-Band
F-Connector	F-Connector * 1 (for Data)
Ethernet Ports	2.5G RJ-45 * 1 1G RJ-45 * 3
Power Adapter	12V, 1A
Operating Temperature Range	0 – 40 °C
Storage Temperature Range	-20 – 80 °C

Weight and Dimensions

Dimension	107 x 107 x 30.6mm
