Verizon ASK-MAE340 User Manual

1. MoCA Ethernet Adapter
The MoCA Ethernet Adapter uses the existing coaxial
wiring in most homes to create a high-speed Ethernet
network connection. The MoCA Ethernet Adapter complies
with MoCA 2.5 standard which can deliver up to 2.5Gbps
wired speed through your existing home coaxial wiring.
With four Ethernet ports, the MoCA Ethernet Adapter
provides wired connections of all your devices including
PC, TV, streaming devices, gaming console, and
Data Reset
more devices to access content simultaneously.
DC Port
2.5G RJ-45 Port 1G RJ-45 Port
1

Verizon ASK-MAE340 Specifications

General

General	ASK-MAE340
Certificates	FCC, UL, MoCA 2.5 Certificate
MoCA Standard	MoCA 2.5
Coax in Frequency	Extended D-Band
F-Connector	F-Connector * 1 (for Data)
Ethernet Ports	2.5G RJ-45 * 1 1G RJ-45 * 3
Power Adapter	12V, 1A
Operating Temperature Range	0 – 40 °C
Storage Temperature Range	-20 – 80 °C

Weight and Dimensions

Dimension	107 x 107 x 30.6mm
