Vermes MDC 3290+ - Abbreviations; Necessary Parts

4
VTK-TR-BA-099e-B
Quick Reference Guide MDV 3252-FH
1.1 Abbreviations
Abbr.
Full name
Abbr.
Full name
CHI
Cartridge Heater Integrated
MDV
MicroDispensing Valve
CTF
Ceramics Tappet, Flat
MFC
Multifunctional Controller
CTK
Cleaning Tool Kit
MHC
Microdispensing Heater Control
FC
Frame Cooling
NFN
Nozzle Fixation Nut
FCV-HF
Flow Control Valve High Frequency
NI
Nozzle Insert
FH
Frame Heater
NU
Nozzle Unit
LED
Light Emitting Diode
PE
Polyethylene
MDC
MicroDispensing Control unit
QRG
Quick Reference Guide
MDFH
MicroDispensing Fluid box Heater
TA
Top Adjust
MDT
MicroDispensing Tool
TTF
Tungsten carbide Tappet Flat
1.2 Necessary Parts
Parts
Ord. no.
MDC 3290
+
1014167
MDV 3252-FH
1014704
Sensor Cable 5 m
1010425
Actuator Cable 5 m
1010901
Fluid Box MDFH-48-CHI-TA
1014058
Cartridge base CHI-HT
1014517
Tightening screw
1010027
Tappet Sealing LX NBR170
1013130
Tappet centering screw LX
1014230
Tappet rod (e.g. TTF15)
1012889
Nozzle insert (e.g. N11-100)
1009837
Nozzle Fixation Nut (e.g. NFN-TA-HC) (HC=Heat Conductive)
1014181
MDFH Isolation Body TA (with screws)
1014122
Heat Conductive Body for MDFH-TA
1014123
Cartridge holder TA 30 ccm (with screws)
1014057
MFC 3000
1014981
Adapter Cable MFC, MDC and Sensor
1013997
FCV Assembly-HF 7.0 bar
1015214
Switching power supply 48 V 4 A M12
1014983
