Rear Panel
Figure 2:
i o a s d f
Rear Panel of the DRM1 MKIV
i
optional TRIGGER inputs for all eight instruments including open/closed hi-hat
(please refer to “Trigger Inputs (optional)” on page 23)
o
Main outputs (OUTPUT LEFT and OUTPUT RIGHT). Please refer to page 6.
a
USB port (sends and receives MIDI data and receives rmware updates). Please
refer to page 7 and “MIDI Functions” on page 19.
s
MIDI sockets (MIDI THRU, MIDI OUT, and MIDI IN). Please refer to page 7 and
“MIDI Functions” on page 19.
d
Power connector
f
POWER switch. Please refer to page 6.
