2.1.2.3 Reset Button
The Reset button on the rear panel of a CSG700 series appliance resets the appliance. The reset functionality
depends on the number of time you press it, as described in Table 3.
The Reset button is recessed so that it is not accidentally pressed while the appliance is operational.
To press the Reset button, use a sharp narrow tool. Each time you press the Reset button, you hear a buzzer sound.
Table 3: Reset Button Press Behavior
Number of Presses Behavior
2 Reset the appliance to the factory-default snapshot.
4 Reset the appliance to the branch prestaging configuration.
6 Reset the appliance to the branch staging configuration.
8 Reset the appliance to branch post-staging configuration.
2.1.2.4 Kensington Security Lock
The Kensington security lock on he rear panel of a CSG700 series appliance is a small metal-enforced hole for
attaching a Kensington lock to secure the appliance.
2.1.2.5 GPS Input
The GPS antenna input on the rear panel of a CSG700 series appliance allows you to connect an external GPS
antenna. When you connect a GPS antenna to the appliance, it automatically identifies the geographical location of
the unit, allowing you to detect any theft or movement of the appliance. Knowing the precise location of the unit
also enables Versa Director to provision devices when the serial number is not mandated for the zero-touch
provisioning (ZTP) process.
2.2 Network Interface Card Modules
The CSG700 series appliance offers interface modularity, providing four Ethernet ports that support two types of
NICs:
 1-GB Ethernet over copper (EoC) port
 1-GB EoC with PoE port
%"#,2/1%"/+"1-,/10,+1%"*,!2)"/")")"!,/11,,/1ï
Figure 1 shows the four RJ-45 connectors for the four Ethernet ports. (1-GB EoC port and for the 1-GB EoC with PoE
port.)
Figure 1: RJ-45 Connectors for 1-GB EoC Port With or Without PoE Port
