MAIN Unit Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

PCB with Components CB2039001

Printed Circuit Board AC041N000 FR0084000 1-

C 1002 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B a1

C 1003 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- B b2

C 1004 CHIP CAP. 6pF 50V CH GRM36CH060B50PT K22178293 1- B b2

C 1005 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b1

C 1006 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b2

C 1007 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- B c2

C 1008 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- B d2

C 1010 CHIP TA.CAP. 2.2uF 6.3V TESVA0J225M1-8R K78080009 1- B d2

C 1011 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e2

C 1012 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2

C 1013 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- B d2

C 1014 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e2

C 1015 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- B d3

C 1016 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 1- B a1

C 1017 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B a1

C 1018 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- B a1

C 1019 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B a1

C 1020 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- B a1

C 1021 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- B a1

C 1024 CHIP CAP. 4pF 50V CH GRM36CH040B50PT K22178291 1- B b2

C 1025 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B b2

C 1026 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- B c2

C 1027 CHIP CAP. 0.5pF 50V CK GRM36CK0R5B50PT K22178285 1- B c2

C 1028 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- B c2

C 1029 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c2

C 1030 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b2

C 1031 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- B c2

C 1032 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B b2

C 1033 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B d2

C 1034 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B d2

C 1035 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B d2

C 1036 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B d1

C 1037 CHIP CAP. 120pF 50V CH UMK105CH121JW-F K22178284 1- B e2

C 1039 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- B d2

C 1040 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 1- B d2

C 1041 CHIP CAP. 68pF 50V CH UMK105CH680JW-F K22178278 1- B d2

C 1042 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B d1

C 1043 CHIP CAP. 2.2uF 10V B GRM42-6B225K10PT K22101801 1- B d2

C 1044 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1

C 1045 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B d1

C 1046 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B d1

C 1047 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- A A2

C 1048 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2

C 1049 CHIP CAP. 0.047uF 10V BJ LMK105BJ473KV-F K22108805 1- A A2

C 1050 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- A A1

C 1051 CHIP CAP. 0.0022uF 50V B UMK105B222KW-F K22178833 1- A A1

C 1052 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- A A1

C 1053 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B a1

C 1054 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B a1

C 1055 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B c2

C 1056 CHIP CAP. 1pF 50V CK GRM36CK010B50PT K22178287 1- B c2

C 1057 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 1058 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- B c1

C 1059 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- B c2

C 1060 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c2

C 1061 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B b2

C 1062 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 1063 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B b2

C 1064 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B e2

C 1065 CHIP CAP. 2.2uF 10V B GRM42-6B225K10PT K22101801 1- A A2

C 1066 CHIP CAP. 0.0033uF 50V B UMK105B332KW-F K22178835 1- A A1

C 1067 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A A1

C 1068 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 1069 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 1070 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A A1

C 1071 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- B a2

C 1072 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- B a2

C 1073 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B a2

C 1074 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- B a2

C 1075 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- B a2

C 1076 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- B a2

C 1077 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B a2

C 1078 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c1

C 1079 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c2
