REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

MAIN Unit Parts List

C 1080 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 1081 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- B c2

C 1083 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c2

C 1084 CHIP CAP. 9pF 50V CH UMK105CH090DW-F K22178257 1- B c1

C 1086 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1087 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B d1

C 1088 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B e2

C 1089 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B e2

C 1090 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 1091 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- A A1

C 1092 CHIP CAP. 0.033uF 10V BJ LMK105BJ333KV-F K22108804 1- A A1

C 1093 CHIP CAP. 470pF 50V B UMK105B471KW-F K22178825 1- A A1

C 1094 CHIP CAP. 0.022uF 16V B EMK105B223KW-F K22128813 1- A B1

C 1095 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- B a2

C 1096 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- B a2

C 1097 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a2

C 1098 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B a2

C 1099 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1100 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B c1

C 1101 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B c1

C 1102 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1103 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1106 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B1

C 1107 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B a2

C 1108 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a2

C 1109 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- B a2

C 1110 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B a2

C 1111 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B a3

C 1112 CHIP CAP. 9pF 50V CH UMK105CH090DW-F K22178257 1- B a2

C 1113 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B a3

C 1114 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B a2

C 1115 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B c1

C 1117 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- B c1

C 1118 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- B b1

C 1119 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b1

C 1120 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B b1

C 1121 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- A D1

C 1123 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A E1

C 1126 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B e1

C 1127 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B e1

C 1128 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B a3

C 1129 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B a2

C 1130 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- B b2

C 1131 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B b3

C 1132 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b1

C 1133 CHIP TA.CAP. 10uF 16V TEMSVB21C106M-8R K78120025 1- A E1

C 1134 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B b1

C 1135 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B a1

C 1136 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- B b1

C 1137 CHIP TA.CAP. 2.2uF 6.3V TESVA0J225M1-8R K78080009 1- A D1

C 1138 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D1

C 1139 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A E1

C 1142 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B c1

C 1143 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B d1

C 1144 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B c2

C 1145 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A C1

C 1146 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A C1

C 1147 CHIP CAP. 680pF 50V B UMK105B681KW-F K22178827 1- A C1

C 1148 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- A A2

C 1149 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B e3

C 1150 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B e3

C 1151 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B b2

C 1152 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B b2

C 1153 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B b2

C 1154 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b2

C 1155 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- B b1

C 1156 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B a1

C 1159 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B a1

C 1160 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A E1

C 1161 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E1

C 1162 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b1

C 1163 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- A E1

C 1164 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A E1

C 1165 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B e2

C 1166 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e2

C 1167 CHIP CAP. 0.022uF 16V B EMK105B223KW-F K22128813 1- B e2
