MAIN Unit Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

C 1169 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b2

C 1170 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B b2

C 1171 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B c2

C 1174 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A E2

C 1175 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A E2

C 1176 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- A A1

C 1177 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A3

C 1178 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A A3

C 1179 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A E2

C 1181 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B e2

C 1182 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B e2

C 1183 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B e2

C 1184 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B e2

C 1185 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c3

C 1186 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c3

C 1187 CHIP CAP. 0.047uF 10V BJ LMK105BJ473KV-F K22108805 1- B c2

C 1190 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- A A2

C 1191 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2

C 1192 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A E2

C 1193 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A A3

C 1194 CHIP TA.CAP. 22uF 16V TEMSVB21C226M-8R K78120028 1- A E2

C 1195 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A E2

C 1196 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A F2

C 1197 AL.ELECTRO.CAP. 220uF 10V SMG1AVB221M 220UF K40109027 1- B a2

C 1198 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- A F2

C 1199 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B f2

C 1200 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B f2

C 1201 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3

C 1202 CHIP CAP. 91pF 50V CH UMK105CH910JW-F K22178281 1- B c3

C 1203 CHIP CAP. 82pF 50V CH UMK105CH820JW-F K22178280 1- B d3

C 1204 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d3

C 1205 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B d3

C 1206 CHIP CAP. 470pF 50V B UMK105B471KW-F K22178825 1- B c2

C 1207 CHIP CAP. 470pF 50V B UMK105B471KW-F K22178825 1- B c2

C 1208 CHIP CAP. 0.047uF 10V BJ LMK105BJ473KV-F K22108805 1- B d2

C 1209 CHIP CAP. 0.022uF 16V B EMK105B223KW-F K22128813 1- A A2

C 1210 CHIP CAP. 0.0033uF 50V B UMK105B332KW-F K22178835 1- A A2

C 1211 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A A3

C 1212 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A A3

C 1213 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2

C 1214 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2

C 1215 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- A E3

C 1216 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1- A A3

C 1217 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B e1

C 1218 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A C1

C 1219 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- A C1

C 1222 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- A D2

C 1223 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- A D2

C 1224 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- A D3

C 1225 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- A D3

C 1226 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2

C 1227 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B c2

C 1228 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- B c2

C 1229 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B c2

C 1230 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2

C 1231 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- A A2

C 1232 CHIP CAP. 0.0022uF 50V B UMK105B222KW-F K22178833 1- A A2

C 1233 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2

C 1234 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2

C 1235 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A E1

C 1236 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1246 CHIP CAP. 220pF 25V CH TMK105CH221JW-F K22148246 1- B a2

CD1001 CERAMIC DISC CDA450C24 H7901430 1- A C2

CF1001 CERAMIC FILTER ALFYM450G=K H3900534 1- A C3

D 1001 DIODE HVC355B(TAPE) G2070588 1- B b2

D 1002 DIODE HVU350TRF G2070380 1- B c1

D 1003 DIODE HSU277TRF G2070118 1- B b2

D 1004 DIODE HVC350B-TRF G2070596 1- B d2

D 1005 DIODE RLS135 TE-11 G2070128 1- B a1

D 1006 DIODE HSU277TRF G2070118 1- B a1

D 1007 DIODE HSU277TRF G2070118 1- B a2

D 1008 DIODE 1SS400 TE61 G2070634 1- B b2

D 1009 DIODE DAN235E TL G2070612 1- B c2

D 1010 DIODE 1SS400 TE61 G2070634 1- B f2

D 1011 DIODE MC2850-T11-1 G2070704 1- B f1

D 1012 LED

12-22SURSYGC/S530-A2/TR8

G2070810 1- A F1
