REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.
LOT
SIDE
LAY ADR
MAIN Unit Parts List
D 1013 LED FA1101F-TR G2070842 1- A C3
D 1014 LED FA1101F-TR G2070842 1- A C1
D 1015 DIODE 1SS400 TE61 G2070634 1- B e2
D 1017 DIODE MC2850-T11-1 G2070704 1- B c3
D 1018 DIODE MC2850-T11-1 G2070704 1- A A2
D 1019 DIODE 1SS400 TE61 G2070634 1- B d2
DS1001 LCD HT-3633-TFZWH G6090139 1- A C2
F 1001 CHIP FUSE 4A KAB-2402-402NA31 Q0000086 1- A E3
FB1001 CHIP COI BLM11P600SPT L1690601 1- A D3
FB1003 CHIP COI BLM11P600SPT L1690601 1- A D3
J 1001 CONNECTOR HSJ1594-010055 P1090896 1- B b3
JP1001 WIRE ASSY ANTENNA CABLE T9318161A 1-
JP1001 WIRE ASSY ANTENNA CABLE T9318161B 5-
L 1001 M.RFC 0.22uH 5% C1608CA-R22J L1691068 1- B b2
L 1002 M.RFC 2.2uH LK1608 2R2K-T L1690634 1- B b2
L 1003 COIL E2 0.28-1.0-6T-R L0022366 1- B a1
L 1004 COIL E2 0.5-1.4-2.5T-L L0022613 1- B a1
L 1005 COIL E2 0.45-1.5-4.5T-L L0022601 1- B a1
L 1006 COIL E2 0.28-1.0-4.5T-R L0022395 1- B b2
L 1007 M.RFC 0.22uH 5% C1608CA-R22J L1691068 1- B c2
L 1008 COIL E2 0.35-1.6-4.5T-L L0022577 1- B a1
L 1009 COIL E2 0.35-1.6-4.5T-L L0022577 1- B a1
L 1010 M.RFC 0.22uH 5% C1608CA-R22J L1691068 1- B c2
L 1011 M.RFC 0.027uH HK1608 27NJ-T L1690521 1- B c2
L 1012 M.RFC 0.022uH HK1608 22NJ-T L1690520 1- B c1
L 1013 COIL E2 0.28-1.0-4.5T-R L0022395 1- B a2
L 1014 M.RFC 0.022uH HK1608 22NJ-T L1690520 1- B c2
L 1015 COIL E2 0.28-1.0-4.5T-R L0022395 1- B a2
L 1016 M.RFC 0.0082uH TFL0816-8N2 L1690490 1- B a2
L 1017 M.RFC 0.015uH TFL0816-15 L1690493 1- B c1
L 1018 COIL E2 0.28-1.0-4.5T-R L0022395 1- B a3
L 1019 COIL E2 0.3-1.7-7T-R L0022372 1- A D1
L 1021 COIL E2 0.28-1.0-4.5T-R L0022395 1- B b3
L 1022 M.RFC 0.039uH TFL0816-39 L1690498 1- B b2
L 1023 COIL E2 0.3-1.7-7T-R L0022372 1- A E1
L 1024 COIL 0.0033uH AS050221-3R3NK L0022635 1- B b1
L 1025 COIL E2 0.45-1.5-4.5T-L L0022601 1- B b1
L 1026 M.RFC 0.068uH HK1608 68NJ-T L1690526 1- B b2
L 1027 CHIP COIL 0.22uH LQN21AR22J04 L1690600 1- B a1
L 1028 M.RFC 0.82uH LK1608 R82K-T L1690417 1- B b2
L 1029 M.RFC 0.15uH HK1608 R15J-T L1690938 1- B d3
L 1030 M.RFC 0.015uH TFL0816-15 L1690493 1- B c1
L 1031 COIL E2 0.4-1.3-2T-L L0022580 1- B b1
MC1001 MIC. ELEMENT EM-100PT M3290029 1- A D1
Q 1001 TRANSISTOR RT1N441U-T11-1 G3070247 1- B b2
Q 1002 IC M62364FP 600D G1093033 1- B e3
Q 1003 FET 2SK508-T2B K52 G3805087B 1- B c2
Q 1004 IC MB15A02PFV1-G-BND-EF G1092541 1- B d1
Q 1005 TRANSISTOR 2SA1602A-T11-1F G3116028F 1- B d1
Q 1006 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A A2
Q 1007 TRANSISTOR 2SC5005-T1 G3350058 1- B c1
Q 1008 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B b1
Q 1009 FET 2SK2035 TE85R G3820357 1- A A2
Q 1010 IC BR93LC46FV-WE2 G1093696 1- B e2
Q 1011 IC M37516F8HP
*
G1093678 1- B e1
Q 1012 TRANSISTOR 2SC5006-T1 G3350068 1- B a2
Q 1013 TRANSISTOR 2SC5227-5-TB G3352278E 1- B c1
Q 1014 TRANSISTOR RT1P441U-T11-1 G3070248 1- B f1
Q 1015 FET 2SK2596BXTL G3825967 1- B c1
Q 1016 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A F2
Q 1017 IC NJM2902V-TE1 G1091679 1- A A1
Q 1018 TRANSISTOR FMW1 T98 G3070009 1- B f3
Q 1019 TRANSISTOR RT1N441U-T11-1 G3070247 1- B e2
Q 1020 TRANSISTOR DTB123EK T146 G3070022 1- B e2
Q 1021 TRANSISTOR CPH6102-TL G3070223 1- B f2
Q 1022 FET 2SK2974-T11 G3829747 1- B b1
Q 1023 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A C2
Q 1024 TRANSISTOR DTC124TE TL G3070128 1- A C2
Q 1025 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B d1
Q 1026 TRANSISTOR 2SA1602A-T11-1F G3116028F 1- B c1
Q 1027 IC LC75834W G1093288 1- A C2
Q 1028 TRANSISTOR FMW1 T98 G3070009 1- B e3
Q 1029 TRANSISTOR CPH6102-TL G3070223 1- B e3
Q 1030 IC NJM2902V-TE1 G1091679 1- A A2
Q 1031 FET 3SK320(TE85L) G4803208 1- B b2
Q 1032 TRANSISTOR IMZ2A T108 G3070060 1- A E1
*
: Requires Firmware, CE53, and CT-42
