Vertex Standard VX-146 Service Manual

19
MAIN Unit Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
Q 1033 IC S-80835CNMC-B8U-T2 G1093606 1- B e2
Q 1034 TRANSISTOR 2SC4215Y TE85R G3342157Y 1- B c2
Q 1035 TRANSISTOR FMW1 T98 G3070009 1- A E2
Q 1036 TRANSISTOR 2SA1602A-T11-1F G3116028F 1- A E2
Q 1037 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A E2
Q 1039 IC NJM2406F-TE1 G1091452 1- A A2
Q 1040 TRANSISTOR RT1N441U-T11-1 G3070247 1- A A2
Q 1041 IC NJM2070M(TE2) G1092944 1- A E2
Q 1042 TRANSISTOR 2SA1602A-T11-1F G3116028F 1- A A2
Q 1043 TRANSISTOR CPH6102-TL G3070223 1- A E2
Q 1044 IC NJM2871AF05(TE1) G1093658 1- B f2
Q 1045 IC TA31136FN(EL) G1091605 1- B c3
Q 1046 TRANSISTOR 2SA1602A-T11-1F G3116028F 1- A C1
R 1001 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- B b2
R 1002 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 1003 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B d2
R 1004 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B d2
R 1005 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- B d2
R 1006 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1007 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d2
R 1008 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B d2
R 1009 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B d2
R 1010 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e3
R 1012 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B d2
R 1013 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B e3
R 1014 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A A1
R 1015 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 1016 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c2
R 1017 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b2
R 1018 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 1019 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d1
R 1020 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B d1
R 1021 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B d1
R 1022 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d2
R 1023 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d2
R 1024 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- B e3
R 1025 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B e3
R 1026 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B d1
R 1027 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d1
R 1028 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d3
R 1029 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d3
R 1030 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- A A2
R 1031 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A A2
R 1032 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- A A2
R 1033 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- A A2
R 1034 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 1035 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- A A1
R 1036 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- A A1
R 1037 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A1
R 1038 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- B c2
R 1039 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- B c2
R 1040 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 1- B c2
R 1041 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 1042 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d2
R 1043 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d2
R 1044 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d2
R 1045 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B d1
R 1046 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A1
R 1048 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B f2
R 1049 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A1
R 1050 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A1
R 1051 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- A A1
R 1052 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A1
R 1053 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- A A1
R 1054 CHIP RES. 1.2M 1/16W 5% RMC1/16S 125JTH J24189062 1- A A1
R 1055 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B c2
R 1056 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B c2
R 1057 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B c1
R 1058 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 1059 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B d1
R 1060 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e1
R 1061 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B f2
R 1062 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B e1
R 1063 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e1
R 1064 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B f2
R 1065 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e2
