105VX-1700 Series (EXP Version) Service Manual

PA-4 Unit (Lot 109~)

Parts List

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR

PCB with Components CS2213101

C 5002 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A B8

C 5003 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 109- A B8

C 5004 AL.ELECTRO.CAP. 220uF 16V RE2-16V221MG3# K40129048 109- A B8

C 5005 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E8

C 5008 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E8

C 5010 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E8

C 5012 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170825 109- A H8

C 5013 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A H8

C 5015 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A H8

C 5016 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A D8

C 5019 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A D8

C 5020 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E7

C 5021 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E7

C 5022 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A C7

C 5024 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A D8

C 5025 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 109- A H7

C 5026 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E8

C 5027 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E7

C 5028 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E7

C 5029 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A D8

C 5030 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A D8

C 5031 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A E7

C 5032 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A C7

C 5033 CHIP CAP. 27pF 50V CH GRM2162C1H270JZ01D K22170221 109- A H7

C 5034 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A H7

C 5036 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 109- A I7

C 5037 AL.ELECTRO.CAP. 10uF 25V EMVA250ADA100MD55G K48140014 109- A I7

C 5039 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170825 109- A I7

C 5041 CHIP CAP. 0.01uF 50V B GRM40B103K50PT K22170826 109- A I7

C 5042 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I5

C 5043 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I7

C 5044 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 109- A G7

C 5045 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A G7

C 5046 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A H7

C 5048 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 109- A I7

C 5049 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I5

C 5050 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 109- A I4

C 5052 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 109- A I5

C 5053 AL.ELECTRO.CAP. 10uF 25V EMVA250ADA100MD55G K48140014 109- A I8

C 5055 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 109- A I4

C 5056 CHIP CAP. 68pF 50V CH GRM1882C1H680JA01D K22174231 109- A G6

C 5057 CHIP CAP. 68pF 50V CH GRM1882C1H680JA01D K22174231 109- A H6

C 5058 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I5

C 5059 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A F7

C 5061 CHIP CAP. 0.01uF 50V B GRM40B103K50PT K22170826 109- A F7

C 5063 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A I4

C 5064 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170825 109- A G7

C 5065 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 109- A I8

C 5066 AL.ELECTRO.CAP. 10uF 25V EMVA250ADA100MD55G K48140014 109- A I5

C 5067 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 109- A G7

C 5068 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 109- A H6

C 5069 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A I4

C 5070 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A I5

C 5071 CHIP CAP. 180pF 50V CH GRM2162C1H181JA01D K22170241 109- A F6

C 5072 CHIP CAP. 180pF 50V CH GRM2162C1H181JA01D K22170241 109- A H7

C 5073 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 109- A I4

C 5075 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A H5

C 5076 CHIP CAP. 470pF 50V B GRM216B11H471KA01D K22170801 109- A G6
