106 VX-1700 Series (EXP Version) Service Manual

PA-4 Unit (Lot 109~)

Parts List

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR

C 5078 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A I4

C 5079 CHIP CAP. 0.1uF 250V X7R GRM32DR72E104KW01L K22245801 109- A G5

C 5080 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A I4

C 5081 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I1

C 5082 CHIP CAP. 0.1uF 250V X7R GRM32DR72E104KW01L K22245801 109- A G5

C 5083 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 109- A I5

C 5084 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 109- A E5

C 5087 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I1

C 5090 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I2

C 5094 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I5

C 5098 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I1

C 5099 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A I5

C 5100 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A E6

C 5101 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A E5

C 5103 FILM CAP. 560pF 100V UC342A5600J-T K33209035 109- A F4

C 5104 FILM CAP. 560pF 100V UC342A5600J-T K33209035 109- A H4

C 5105 AL.ELECTRO.CAP. 1000uF 16V RE3-16V102MH3# K40129096 109- A H1

C 5106 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 109- A H1

C 5107 CERAMIC CAP. 0.0068uF 200V SL GRM55R1X2D682JV01L K22236101 109-137 AG5

C 5107 CERAMIC CAP. 0.0068uF 1kV U2J GRM55Q7U3A682JW31L K22306201 138- A G5

C 5108 CERAMIC CAP. 0.0068uF 200V SL GRM55R1X2D682JV01L K22236101 109-137 AG5

C 5108 CERAMIC CAP. 0.0068uF 1kV U2J GRM55Q7U3A682JW31L K22306201 138- A G5

C 5110 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A H2

C 5111 FILM CAP. 220pF 500V UC342H2200J-T K33279011 109- A G3

C 5112 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A H2

C 5113 CHIP CAP. 0.1uF 50V B GRM42-6B104K50PT K22171820 109- A G1

C 5114 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A G1

C 5115 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 109- A G1

C 5119 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A E6

C 5120 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A E5

C 5121 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A E5

C 5122 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A E4

C 5123 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A E3

C 5124 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A E2

C 5125 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A E1

C 5126 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A D1

C 5128 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 109- A C1

C 5129 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A C1

C 5130 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 109- A C1

C 5131 CHIP CAP. 0.001uF 500V CH CF43CH102J500AT K22277222 109- A D7

C 5132 CHIP CAP. 820pF 500V CH 1206N821J501LT K22278232 109- A D6

C 5133 CHIP CAP. 560pF 500V CH 1206N561J501LT K22278230 109- A D5

C 5134 CHIP CAP. 220pF 500V CH 1206N221J501LT K22278225 109- A D4

C 5135 CHIP CAP. 120pF 250V C0G GRM21A5C2E121JW01D K22240314 109- A D3

C 5136 CHIP CAP. 100pF 500V CH 1206N101J501LT K22278221 109- A D3

C 5137 CHIP CAP. 39pF 250V C0G GRM21A5C2E390JW01D K22240308 109- A D2

C 5138 CHIP CAP. 330pF 500V CH 1206N331J501LT K22278227 109- A D7

C 5139 CHIP CAP. 39pF 250V C0G GRM21A5C2E390JW01D K22240308 109- A E6

C 5141 CHIP CAP. 180pF 500V CH 1206N181J501LT K22278224 109- A E4

C 5142 CHIP CAP. 100pF 250V C0G GRM21A5C2E101JW01D K22240313 109- A D3

C 5143 CHIP CAP. 33pF 250V C0G GRM21A5C2E330JW01D K22240307 109- A E3

C 5144 CHIP CAP. 39pF 250V C0G GRM21A5C2E390JW01D K22240308 109- A D2

C 5145 CHIP CAP. 220pF 500V CH 1206N221J501LT K22278225 109- A D7

C 5146 CHIP CAP. 10pF 250V C0G GRM21A5C2E100JW01D K22240301 109- A D7

C 5147 CHIP CAP. 82pF 250V C0G GRM21A5C2E820JW01D K22240312 109- A D5

C 5148 CHIP CAP. 68pF 250V C0G GRM21A5C2E680JW01D K22240311 109- A D5

C 5149 CHIP CAP. 100pF 500V CH 1206N101J501LT K22278221 109- A D6

C 5151 CHIP CAP. 27pF 250V C0G GRM21A5C2E270JW01D K22240306 109- A D4

C 5152 CHIP CAP. 22pF 250V C0G GRM21A5C2E220JW01D K22240305 109- A D4
