107VX-1700 Series (EXP Version) Service Manual

PA-4 Unit (Lot 109~)

Parts List

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR

C 5153 CHIP CAP. 39pF 250V C0G GRM21A5C2E390JW01D K22240308 109- A D4

C 5154 CHIP CAP. 10pF 250V C0G GRM21A5C2E100JW01D K22240301 109- A D4

C 5155 CHIP CAP. 22pF 250V C0G GRM21A5C2E220JW01D K22240305 109- A D2

C 5156 CHIP CAP. 10pF 250V C0G GRM21A5C2E100JW01D K22240301 109- A D2

C 5157 CHIP CAP. 8pF 200V CH GRM2192C2D8R0DY21D K22230214 109-136 AD3

C 5157 CHIP CAP. 8pF 250V C0G GQM2195C2E8R0DB12D K22240251 137- A D3

C 5158 CHIP CAP. 8pF 200V CH GRM2192C2D8R0DY21D K22230214 109-136 AD3

C 5158 CHIP CAP. 8pF 250V C0G GQM2195C2E8R0DB12D K22240251 137- A D3

C 5159 CHIP CAP. 330pF 500V CH 1206N331J501LT K22278227 109- A C7

C 5160 CHIP CAP. 0.001uF 500V CH CF43CH102J500AT K22277222 109- A C7

C 5161 CHIP CAP. 820pF 500V CH 1206N821J501LT K22278232 109- A D6

C 5162 CHIP CAP. 470pF 500V CH 1206N471J501LT K22278229 109- A C5

C 5163 CHIP CAP. 470pF 500V CH 1206N471J501LT K22278229 109- A D5

C 5164 CHIP CAP. 180pF 500V CH 1206N181J501LT K22278224 109- A C3

C 5165 CHIP CAP. 150pF 500V CH 1206N151J501LT K22278223 109- A D3

C 5166 CHIP CAP. 150pF 500V CH 1206N151J501LT K22278223 109- A C2

C 5167 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 109- A B1

C 5168 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 109- A B1

C 5169 CHIP CAP. 560pF 500V CH 1206N561J501LT K22278230 109- A C7

C 5170 CHIP CAP. 390pF 500V CH 1206N391J501LT K22278228 109- A D6

C 5171 CHIP CAP. 330pF 500V CH 1206N331J501LT K22278227 109- A C5

C 5172 CHIP CAP. 180pF 500V CH 1206N181J501LT K22278224 109- A D5

C 5173 CHIP CAP. 150pF 500V CH 1206N151J501LT K22278223 109- A C3

C 5174 CHIP CAP. 100pF 500V CH 1206N101J501LT K22278221 109- A D3

C 5176 CHIP CAP. 330pF 500V CH 1206N331J501LT K22278227 109- A C5

C 5177 CHIP CAP. 120pF 250V C0G GRM21A5C2E121JW01D K22240314 109- A C5

C 5178 CHIP CAP. 680pF 500V CH CF43CH681J500AT K22277218 109- A C7

C 5179 CHIP CAP. 18pF 250V C0G GRM21A5C2E180JW01D K22240304 109- A C7

C 5180 CHIP CAP. 270pF 500V CH 1206N271J501LT K22278226 109- A C6

C 5181 CHIP CAP. 27pF 250V C0G GRM21A5C2E270JW01D K22240306 109- A C6

C 5182 CHIP CAP. 100pF 250V C0G GRM21A5C2E101JW01D K22240313 109- A C4

C 5183 CHIP CAP. 47pF 250V C0G GRM21A5C2E470JW01D K22240309 109- A C4

C 5184 CHIP CAP. 120pF 250V C0G GRM21A5C2E121JW01D K22240314 109- A C4

C 5186 CHIP CAP. 47pF 250V C0G GRM21A5C2E470JW01D K22240309 109- A C2

C 5187 CHIP CAP. 27pF 250V C0G GRM21A5C2E270JW01D K22240306 109- A C2

C 5188 CHIP CAP. 27pF 250V C0G GRM21A5C2E270JW01D K22240306 109- A C3

C 5189 CHIP CAP. 22pF 250V C0G GRM21A5C2E220JW01D K22240305 109- A C3

C 5190 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 109- A B1

C 5191 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 109- A B1

C 5192 CHIP CAP. 0.001uF 500V CH CF43CH102J500AT K22277222 109- A B7

C 5193 CHIP CAP. 820pF 500V CH 1206N821J501LT K22278232 109- A C6

C 5194 CHIP CAP. 560pF 500V CH 1206N561J501LT K22278230 109- A B5

C 5195 CHIP CAP. 270pF 500V CH 1206N271J501LT K22278226 109- A C5

C 5196 CHIP CAP. 180pF 500V CH 1206N181J501LT K22278224 109- A B3

C 5197 CHIP CAP. 120pF 500V CH 1206N121J501LT K22278222 109- A C3

C 5198 CHIP CAP. 56pF 500V CH 1206N560J501LT K22278218 109- A B2

C 5199 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 109- A B1

C 5200 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 109- A B1

C 5201 CHIP CAP. 470pF 500V CH 1206N471J501LT K22278229 109- A B7

C 5202 CHIP CAP. 120pF 500V CH 1206N121J501LT K22278222 109- A C6

C 5203 CHIP CAP. 56pF 250V C0G GRM21A5C2E560JW01D K22240310 109- A B5

C 5204 CHIP CAP. 270pF 500V CH 1206N271J501LT K22278226 109- A C5

C 5205 CHIP CAP. 82pF 250V C0G GRM21A5C2E820JW01D K22240312 109- A B3

C 5206 CHIP CAP. 100pF 500V CH 1206N101J501LT K22278221 109- A C3

C 5207 CHIP CAP. 56pF 500V CH 1206N560J501LT K22278218 109- A B2

C 5208 CHIP CAP. 10pF 250V C0G GRM21A5C2E100JW01D K22240301 109- A B1

C 5209 CHIP CAP. 820pF 500V CH 1206N821J501LT K22278232 109- A B7

C 5210 CHIP CAP. 680pF 500V CH 1206N681J501LT K22278231 109- A B7

C 5211 CHIP CAP. 100pF 500V CH 1206N101J501LT K22278221 109- A B7
