108 VX-1700 Series (EXP Version) Service Manual

PA-4 Unit (Lot 109~)

Parts List

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR

C 5212 CHIP CAP. 560pF 500V CH 1206N561J501LT K22278230 109- A B5

C 5213 CHIP CAP. 560pF 500V CH 1206N561J501LT K22278230 109- A B5

C 5214 CHIP CAP. 560pF 500V CH 1206N561J501LT K22278230 109- A B6

C 5216 CHIP CAP. 180pF 500V CH 1206N181J501LT K22278224 109- A B4

C 5217 CHIP CAP. 150pF 500V CH 1206N151J501LT K22278223 109- A B4

C 5218 CHIP CAP. 270pF 500V CH 1206N271J501LT K22278226 109- A B4

C 5219 CHIP CAP. 27pF 250V C0G GRM21A5C2E270JW01D K22240306 109- A B4

C 5220 CHIP CAP. 100pF 500V CH 1206N101J501LT K22278221 109- A B2

C 5221 CHIP CAP. 56pF 250V C0G GRM21A5C2E560JW01D K22240310 109- A B2

C 5222 CHIP CAP. 68pF 250V C0G GRM21A5C2E680JW01D K22240311 109- A B3

C 5223 CHIP CAP. 39pF 250V C0G GRM21A5C2E390JW01D K22240308 109- A B3

C 5224 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 109- A B1

C 5226 CHIP CAP. 560pF 500V CH 1206N561J501LT K22278230 109- A A7

C 5227 CHIP CAP. 390pF 500V CH 1206N391J501LT K22278228 109- A A6

C 5228 CHIP CAP. 270pF 500V CH 1206N271J501LT K22278226 109- A A5

C 5229 CHIP CAP. 150pF 500V CH 1206N151J501LT K22278223 109- A A4

C 5230 CHIP CAP. 100pF 500V CH 1206N101J501LT K22278221 109- A A3

C 5231 CHIP CAP. 33pF 500V CH 1206N330J501LT K22278215 109- A A3

C 5232 CHIP CAP. 22pF 500V CH 1206N220J501LT K22278213 109- A A2

C 5233 CHIP CAP. 100pF 250V C0G GRM21A5C2E101JW01D K22240313 109- A A7

C 5234 CHIP CAP. 39pF 250V C0G GRM21A5C2E390JW01D K22240308 109- A A6

C 5237 CHIP CAP. 22pF 500V CH 1206N220J501LT K22278213 109- A A2

C 5238 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A A7

C 5239 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A A6

C 5240 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A A5

C 5241 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A A5

C 5242 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A A4

C 5243 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A A3

C 5244 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A A2

C 5245 CHIP CAP. 82pF 250V C0G GRM21A5C2E820JW01D K22240312 109- A A4

C 5254 CHIP CAP. 10pF 50V CH GRM2162C1H100JZ01D K22170211 109-130 AD1

C 5254 CHIP CAP. 10pF 50V CH 0805N100J500CT K22175211 131- A D1

C 5255 CHIP CAP. 82pF 50V CH GRM2162C1H820JZ01D K22170233 109-134 AC1

C 5255 CHIP CAP. 82pF 50V CH 0805N820J500CT K22175221 135- A C1

C 5256 CHIP CAP. 82pF 50V CH GRM2162C1H820JZ01D K22170233 109-134 AD1

C 5256 CHIP CAP. 82pF 50V CH 0805N820J500CT K22175221 135- A D1

C 5257 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 109- A E7

C 5258 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 109- A E7

C 5259 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 109- A F7

C 5260 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 109- A F8

C 5261 AL.ELECTRO.CAP. 1uF 50V RE2-50V010ME3#-T2 K46170017 109- A F7

C 5401 FILM CAP. 0.0015uF 100V UC552A1501J-T K33209040 109-

D 5001 DIODE BAS316 G2070716 109- A I8

D 5002 DIODE BAS316 G2070716 109- A J7

D 5003 DIODE BAS316 G2070716 109- A I7

D 5004 DIODE BAS316 G2070716 109- A G7

D 5005 DIODE SM240LA-T G2071156 109- A J3

D 5006 DIODE BAS316 G2070716 109- A I3

D 5007 DIODE UDZS TE-17 16B G2070914 109- A I3

D 5008 DIODE BAS316 G2070716 109- A I3

D 5009 DIODE BAS316 G2070716 109- A J3

D 5010 DIODE DAN202U T106 G2070162 109- A I5

D 5011 DIODE DAN202U T106 G2070162 109- A E5

D 5012 DIODE BAS316 G2070716 109- A E6

D 5013 DIODE BAS316 G2070716 109- A E5

D 5014 DIODE BAS316 G2070716 109- A E5

D 5015 DIODE BAS316 G2070716 109- A E4

D 5016 DIODE BAS316 G2070716 109- A E3

D 5017 DIODE BAS316 G2070716 109- A E2
