18 VX-1700 Series (EXP Version) Service Manual
Software Menu Alignment
The ANT jack should be connected to a Dummy Load
(in the case of transmission) or RF Signal Generator
(in the case of reception). General alignment condi-
tions are as follows, unless otherwise noted.
VOL Knob: Center (12 o’clock position).
SQL Knob: Fully counter-clockwise.
TX Output Power: HIGH
VOX:Off
The channel data in the radio is preset per the chart
below.
Press and hold in the keypad’s
[
1
(
MODE
)]
,
[
4
(
STEP
)]
,
[
7
(
V/M
)]
, and
[
F
]
keys simultaneously,
and turn on the radio while holding them in; the
alignment menu will then be activated.
In the alignment procedures, each alignment param-
eter is selected by pressing the
[
ALARM
]
/
[
2128
]
key.
Each alignment item is selected by rotating the CH
Knob. To store the alignment parameters when you
are satisfied with the adjustment, press the
[
F
]
key
for longer than a half second.
Note that a few alignment parameters are not ad-
justable, and are to be left as set at the factory.
TX OUTPUT POWER ALIGNMENT
 Connect the 50 Ohm Dummy Load and Inline
Wattmeter to the ANT jack.
 Referring to the Table below, press the
[
ALARM
]
/
[
2128
]
key to recall each parameter listed, then
key the transmitter (connect pin 3 of the MIC jack
to GND) and rotate the CH knob for the required
output.
Channel
1-001
1-002
1-003
1-004
1-005
1-006
1-007
Frequency
1.7000 MHz
3.5000 MHz
5.5000 MHz
7.5000 MHz
12.0000 MHz
19.8000 MHz
29.0000 MHz
Alignment
Parameter
1PO-VH
1PO-H
1PO-MH
1PO-ML
1PO-L
2PO-VH
2PO-H
2PO-MH
2PO-ML
2PO-L
3PO-H
3PO-MH
3PO-ML
3PO-L
4PO-H
4PO-MH
4PO-ML
4PO-L
Output Power
125 W (± 5 W)
100 W (± 5 W)
50 W (± 5 W)
25 W (± 1 W)
10 W (± 1 W)
125 W (± 5 W)
100 W (± 5 W)
50 W (± 5 W)
25 W (± 1 W)
10 W (± 1 W)
100 W (± 5 W)
50 W (± 5 W)
25 W (± 1 W)
10 W (± 1 W)
100 W (± 5 W)
50 W (± 5 W)
25 W (± 1 W)
10 W (± 1 W)
Parameter
5PO-H
5PO-MH
5PO-ML
5PO-L
6PO-H
6PO-MH
6PO-ML
6PO-L
7PO-H
7PO-MH
7PO-ML
7PO-L
Output Power
100 W (± 5 W)
50 W (± 5 W)
25 W (± 1 W)
10 W (± 1 W)
100 W (± 5 W)
50 W (± 5 W)
25 W (± 1 W)
10 W (± 1 W)
100 W (± 5 W)
50 W (± 5 W)
25 W (± 1 W)
10 W (± 1 W)
