84 VX-1700 Series (EXP Version) Service Manual
Parts List
MAIN Unit
R 1284 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A F7
R 1285 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F6
R 1286 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F6
R 1287 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- A C7
R 1288 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1- A D7
R 1289 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A G5
R 1290 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D6
R 1291 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A D5
R 1292 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- A D6
R 1293 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A G5
R 1294 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D7
R 1295 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D7
R 1296 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A D5
R 1297 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A G4
R 1298 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A F5
R 1299 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E6
R 1300 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E6
R 1301 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D7
R 1302 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D7
R 1303 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A E6
R 1304 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A F6
R 1305 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A E7
R 1306 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A F6
R 1307 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A G5
R 1308 CHIP RES. 10 1/16W 5% RMC1/16 100JATP J24185100 1- A E6
R 1309 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A G4
R 1310 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A F4
R 1311 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E7
R 1312 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E7
R 1313 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A G5
R 1314 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A G5
R 1315 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A E7
R 1316 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D6
R 1317 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A E5
R 1318 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E6
R 1319 CHIP RES. 22 1/16W 5% RMC1/16 220JATP J24185220 1- A E6
R 1320 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- A I3
R 1321 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A J3
R 1322 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A J3
R 1323 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A H5
R 1324 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A F5
R 1325 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J2
R 1326 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- A J2
R 1327 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J2
R 1328 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J2
R 1329 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J2
R 1330 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J3
R 1331 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J3
R 1333 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J4
R 1334 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J4
R 1335 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J4
R 1336 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J4
R 1337 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J4
R 1338 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J4
R 1339 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A J4
R 1340 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-6
R 1341 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1-6
R 1342 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-6
R 1343 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1-6
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
