86 VX-1700 Series (EXP Version) Service Manual
MAIN Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
T 1002 COIL WIDE-TRANS. 080812764 L0023036 45- A H1
T 1003 COIL WIDE-TRANS. 040812480 L0022904 1-44 A I1
T 1003 COIL WIDE-TRANS. 080812764 L0023036 45- A I1
T 1004 COIL WIDE-TRANS. 040812480 L0022904 1-44 A I5
T 1004 COIL WIDE-TRANS. 080812764 L0023036 45- A I5
T 1005 COIL WIDE-TRANS. EKMA07PB07 L0021123 1- A I5
T 1006 COIL WIDE-TRANS. 040812479 L0022905 1-44 A I6
T 1006 COIL WIDE-TRANS. 080812765 92H5 L0023037 45- A I6
T 1007 COIL WIDE-TRANS. 040812479 L0022905 1-44 A I6
T 1007 COIL WIDE-TRANS. 080812765 92H5 L0023037 45- A I6
T 1008 COIL 07RF 47MHz 47.0M L0021546 1-108 A I7
T 1008 COIL 07RF 47MHz LKHC918619 L0023177 109- A I7
T 1009 COIL 07RF 47MHz 47.0M L0021536 1-108 A H7
T 1009 COIL 07RF 47MHz 47.0M LKHC918730 L0023179 109- A H7
T 1010 COIL 07RF 47MHz 47.0M L0021537 1-108 A H6
T 1010 COIL 07RF 47MHz 47.0M LKHC918731 L0023178 109- A H6
T 1011 COIL 07RF 47MHz 47.0M L0021546 1-108 A G7
T 1011 COIL 07RF 47MHz LKHC918619 L0023177 109- A G7
T 1012 COIL 07RF 47MHz 47.0M L0021546 1-108 A G6
T 1012 COIL 07RF 47MHz LKHC918619 L0023177 109- A G6
T 1013 COIL 07RF 90MHz 90.0M R12-S602A L0020803 1- A D5
TH1001 THERMISTOR 157-152-53009-TP G9090123 1-96 A G6
TH1001 THERMISTOR 157-501-53009TP G9090058 97- A G6
X 1002 XTAL OSC 36.864MHz TPS11XC 36.864MHZ H9500770 1-106 A C5
X 1002 XTAL OSC 36.864MHz TPS11XCK-G2 36.8 H9501420 107-108 A C5
X 1002 XTAL OSC 36.864MHz TPS11XCK-G2 36.864MHZ H9501440 109- A C5
X 1003 TCXO 22.625MHz TTS01NS-P1 22.625MHZ H9500840 1-107 A D5
X 1003 TCXO 22.625MHz NTO-801BS 22.625MHZ H9501430 108- A D5
X 1004 XTAL TSS-6035B 19.82MHz 19.820MHZ H0103262 1-6 A C3
X 1004 XTAL TSS-6035B 19.82MHz 19.820MHZ H0103262A 7- A C3
XF1001 XTAL FILTER MFT45N 45.275MHZ H1102390 1- A H7
SHIELD CASE R0128100 1-
SHIELD CASE COVER R0128110 1-
SHIELD CASE R0131630 1-
