95VX-1700 Series (EXP Version) Service Manual

PA Unit (Lot 1~108)

Parts List

PCB with Components CS1842001

C 2001 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A I8

C 2001 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A I8

C 2002 CHIP CAP. 470pF 50V B GRM188B11H471KA01D K22174805 1- A I8

C 2003 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A I7

C 2003 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A I7

C 2004 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 1- A H7

C 2005 AL.ELECTRO.CAP. 10uF 50V RE2-50V100ME3#-T2 K46170021 1- A H7

C 2006 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A H7

C 2008 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A I1

C 2009 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 1- A H7

C 2010 AL.ELECTRO.CAP. 1uF 50V RE2-50V010ME3#-T2 K46170017 1- A G8

C 2011 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A H7

C 2012 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1-27 A G7

C 2012 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 28- A G7

C 2013 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D8

C 2015 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A H6

C 2017 AL.ELECTRO.CAP. 1uF 50V RE2-50V010ME3#-T2 K46170017 1- A G8

C 2018 CHIP CAP. 68pF 50V CH GRM1882C1H680JA01D K22174231 1- A G6

C 2019 CHIP CAP. 68pF 50V CH GRM1882C1H680JA01D K22174231 1- A G6

C 2021 AL.ELECTRO.CAP. 10uF 50V RE2-50V100ME3#-T2 K46170021 1- A I6

C 2025 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F7

C 2027 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A G8

C 2027 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A G8

C 2029 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 1- A G6

C 2030 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 1- A H5

C 2031 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A J4

C 2031 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A J4

C 2034 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A I5

C 2034 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A I5

C 2036 CHIP CAP. 150pF 200V CH GRM21B2C2D151JV01L K22230230 1- A G6

C 2037 AL.ELECTRO.CAP. 10uF 50V RE2-50V100ME3#-T2 K46170021 1- A I3

C 2040 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F6

C 2042 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A G6

C 2044 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E8

C 2047 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A I4

C 2047 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A I4

C 2048 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A H8

C 2048 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A H8

C 2049 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E8

C 2050 AL.ELECTRO.CAP. 10uF 50V RE2-50V100ME3#-T2 K46170021 1- A I5

C 2051 CHIP CAP. 0.1uF 250V X7R GRM32DR72E104KW01L K22245801 1- A G5

C 2052 CHIP CAP. 0.1uF 250V X7R GRM32DR72E104KW01L K22245801 1- A H4

C 2053 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E6

C 2054 AL.ELECTRO.CAP. 1000uF 16V RE3-16V102MH3# K40129096 1- A I2

C 2055 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A H2

C 2055 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A H2

C 2057 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A H8

C 2057 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A H8

C 2058 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1 A H1

C 2060 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A H2

C 2062 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A I2

C 2064 CHIP CAP. 0.1uF 250V X7R GRM32DR72E104KW01L K22245801 1- A F3

C 2065 CHIP CAP. 0.1uF 250V X7R GRM32DR72E104KW01L K22245801 1- A H3

C 2066 FILM CAP. 330pF 500V UC342H3300J-T K33279014 1- A F3

C 2067 FILM CAP. 330pF 500V UC342H3300J-T K33279014 1- A G3

C 2068 AL.ELECTRO.CAP. 1uF 50V RE2-50V010ME3#-T2 K46170017 1- A H8

C 2070 CHIP CAP. 0.047uF 50V B GRM21BB11H473KA01L K22170823 1- A H1

C 2071 CHIP CAP. 0.1uF 50V B GRM42-6B104K50PT K22171820 1- A H1

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR
