96 VX-1700 Series (EXP Version) Service Manual

PA Unit (Lot 1~108)

Parts List

C 2072 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A H8

C 2073 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1-27 A G1

C 2073 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 28- A G1

C 2074 AL.ELECTRO.CAP. 10uF 50V RE2-50V100ME3#-T2 K46170021 1- A F1

C 2076 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A D7

C 2076 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A D7

C 2077 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A D6

C 2077 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A D6

C 2078 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A D5

C 2078 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A D5

C 2079 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A D4

C 2079 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A D4

C 2080 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A D3

C 2080 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A D3

C 2081 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A D2

C 2081 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A D2

C 2082 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A D2

C 2082 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A D2

C 2084 CHIP CAP. 0.001uF 500V CH CF43CH102J500AT K22277222 1- A D7

C 2085 CHIP CAP. 820pF 500V CH CF43CH821J500AT K22277220 1- A E6

C 2086 CHIP CAP. 470pF 500V CH CF43CH471J500AT K22277214 1- A D5

C 2087 CHIP CAP. 220pF 500V CH CF43CH221J500AT K22277206 1- A E4

C 2088 CHIP CAP. 100pF 200V CH GRM21B2C2D101JV01L K22230228 1- A D3

C 2089 CHIP CAP. 68pF 200V CH GRM21B2C2D680JV01L K22230226 1- A D3

C 2090 CHIP CAP. 56pF 200V CH GRM2192C2D560JV01D K22230225 1- A D2

C 2091 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A C1

C 2091 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A C1

C 2092 CHIP CAP. 560pF 500V CH CF43CH561J500AT K22277216 1- A D7

C 2098 CHIP CAP. 10pF 200V CH GRM2192C2D100JV01D K22230216 1- A D2

C 2099 CHIP CAP. 220pF 500V CH CF43CH221J500AT K22277206 1- A D8

C 2101 CHIP CAP. 220pF 200V CH GRM21B2C2D221JY21L K22230232 1-96 A D5

C 2101 CHIP CAP. 220pF 250V CH GRM21A5C2E221JW01D K22240242 97- A D5

C 2102 CHIP CAP. 33pF 200V CH GRM2192C2D330JV01D K22230222 1- A D5

C 2103 CHIP CAP. 39pF 200V CH GRM2192C2D390JV01D K22230223 1- A D6

C 2105 CHIP CAP. 100pF 200V CH GRM21B2C2D101JV01L K22230228 1- A D4

C 2107 CHIP CAP. 22pF 200V CH GRM2192C2D220JV01D K22230220 1- A D4

C 2109 CHIP CAP. 27pF 200V CH GRM2192C2D270JV01D K22230221 1- A D2

C 2110 CHIP CAP. 10pF 200V CH GRM2192C2D100JV01D K22230216 1- A D2

C 2111 CHIP CAP. 27pF 200V CH GRM2192C2D270JV01D K22230221 1- A D3

C 2113 CHIP CAP. 0.001uF 500V CH CF43CH102J500AT K22277222 1- A C7

C 2114 CHIP CAP. 560pF 500V CH CF43CH561J500AT K22277216 1- A D6

C 2115 CHIP CAP. 680pF 500V CH CF43CH681J500AT K22277218 1- A C5

C 2116 CHIP CAP. 470pF 500V CH CF43CH471J500AT K22277214 1- A D4

C 2117 CHIP CAP. 270pF 500V CH CF43CH271J500AT K22277208 1- A C3

C 2118 FILM CAP. 150pF 500V UC342H1500J-T K33279012 1- A D3

C 2119 FILM CAP. 100pF 500V UC342H1000J-T K33279031 1- A C2

C 2120 CHIP CAP. 820pF 500V CH CF43CH821J500AT K22277220 1- A C7

C 2124 FILM CAP. 33pF 500V UC232H0330J-T K33279024 1- A C3

C 2125 FILM CAP. 82pF 500V UC232H0820J-T K33279033 1- A C3

C 2126 FILM CAP. 39pF 500V UC232H0390J-T K33279038 1- A C2

C 2137 CHIP CAP. 82pF 200V CH GRM21B2C2D820JV01L K22230227 1- A C2

C 2138 CHIP CAP. 10pF 200V CH GRM2192C2D100JV01D K22230216 1- A C2

C 2141 CHIP CAP. 10pF 200V CH GRM2192C2D100JV01D K22230216 1- A B1

C 2142 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A B1

C 2144 FILM CAP. 100pF 500V UC342H1000J-T K33279031 1- A B7

C 2145 CHIP CAP. 470pF 500V CH CF43CH471J500AT K22277214 1- A C6

C 2151 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1 A I1

C 2158 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1-27 A B1

C 2158 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 28- A B1

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR
