97VX-1700 Series (EXP Version) Service Manual

PA Unit (Lot 1~108)

Parts List

C 2159 CHIP CAP. 560pF 500V CH CF43CH561J500AT K22277216 1- A B8

C 2162 CHIP CAP. 68pF 200V CH GRM21B2C2D680JV01L K22230226 1- A B5

C 2164 CHIP CAP. 100pF 200V CH GRM21B2C2D101JV01L K22230228 1- A B6

C 2166 CHIP CAP. 27pF 200V CH GRM2192C2D270JV01D K22230221 1- A B4

C 2168 CHIP CAP. 39pF 200V CH GRM2192C2D390JV01D K22230223 1- A B4

C 2171 CHIP CAP. 47pF 200V CH GRM2192C2D470JV01D K22230224 1- A B3

C 2172 CHIP CAP. 10pF 200V CH GRM2192C2D100JV01D K22230216 1- A B3

C 2173 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1- A B2

C 2174 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1-27 A B1

C 2174 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 28- A B1

C 2175 CHIP CAP. 680pF 500V CH CF43CH681J500AT K22277218 1- A A6

C 2176 CHIP CAP. 680pF 500V CH CF43CH681J500AT K22277218 1- A A6

C 2177 CHIP CAP. 330pF 500V CH CF43CH331J500AT K22277210 1- A A5

C 2178 CHIP CAP. 220pF 200V CH GRM21B2C2D221JY21L K22230232 1-96 A A4

C 2178 CHIP CAP. 220pF 250V CH GRM21A5C2E221JW01D K22240242 97- A A4

C 2179 CHIP CAP. 150pF 200V CH GRM21B2C2D151JV01L K22230230 1- A A4

C 2180 CHIP CAP. 27pF 200V CH GRM2192C2D270JV01D K22230221 1- A A3

C 2181 CHIP CAP. 22pF 200V CH GRM2192C2D220JV01D K22230220 1- A A2

C 2182 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A B2

C 2183 CHIP CAP. 100pF 200V CH GRM21B2C2D101JV01L K22230228 1- A A6

C 2186 CHIP CAP. 47pF 200V CH GRM2192C2D470JV01D K22230224 1- A A4

C 2188 CHIP CAP. 22pF 200V CH GRM2192C2D220JV01D K22230220 1- A A3

C 2190 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A A7

C 2190 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A A7

C 2191 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A A6

C 2191 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A A6

C 2192 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A A5

C 2192 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A A5

C 2193 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A A5

C 2193 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A A5

C 2194 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A A4

C 2194 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A A4

C 2195 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A A3

C 2195 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A A3

C 2196 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-27 A A2

C 2196 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 28- A A2

C 2198 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1 A I1

C 2199 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A E7

C 2201 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D8

C 2203 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A I5

C 2204 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E8

C 2205 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E7

C 2301 CHIP CAP. 680pF 500V CH CF43CH681J500AT K22277218 1-

C 2302 FILM CAP. 820pF 500V UC552H8200J-T K33279016 1-

C 2303 FILM CAP. 470pF 500V UC342H4700J-T K33279015 1-3

C 2303 FILM CAP. 470pF 500V UC342H4700J-T K33279015 4-

D 2001 DIODE BAS316 G2070716 1- A G7

D 2002 DIODE UDZS TE-17 16B G2070914 1- A F6

D 2003 DIODE 10EDB10 G2090781 1- A I4

D 2004 DIODE DAN202K T146 G2070182 1- A G8

D 2005 DIODE 10EDB10 G2090781 1- A H3

D 2006 DIODE BAS316 G2070716 1- A H2

D 2007 DIODE BAS316 G2070716 1- A H2

D 2008 DIODE BAS316 G2070716 7- A E7

D 2009 DIODE BAS316 G2070716 7- A E6

D 2010 DIODE BAS316 G2070716 7- A E5

D 2011 DIODE BAS316 G2070716 7- A E4

D 2012 DIODE BAS316 G2070716 7- A E3

D 2013 DIODE BAS316 G2070716 7- A E2

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR
