98 VX-1700 Series (EXP Version) Service Manual
PA Unit (Lot 1~108)
Parts List
D 2014 DIODE BAS316 G2070716 7- A E2
D 2015 SURGE ABSORBER RHCA-301Q43U Q9000827 1- A C1
D 2016 DIODE BAS316 G2070716 1- A C1
D 2017 DIODE MA729-(TX) G2070320 1-100 A B1
D 2017 DIODE DB2J31300L G2071338 101- A B1
D 2018 DIODE MA729-(TX) G2070320 1-100 A B2
D 2018 DIODE DB2J31300L G2071338 101- A B2
D 2026 DIODE RB060L-40 TE25 G2070744 1- A F7
D 2027 DIODE UDZS TE-17 6.8B G2070888 1- A F7
J 2001 CONNECTOR TMP-J01X-A2 P1090255 1-6 A I8
J 2001 CONNECTOR TMP-S01X-C1 P1091254 7- A I8
J 2002 CONNECTOR 30FLT-SM2-TB(LF)(SN)(M) P1091142 1- A D8
J 2003 CONNECTOR IMSA-9202B-1-02-T P0091174 1- A H7
J 2004 CONNECTOR IMSA-9202B-1-02-T P0091174 1- A J3
J 2005 CONNECTOR B2B-ZR-SM4-TFT(LF)(SN) P0091342 1- A C8
J 2006 CONNECTOR TMP-J01X-A2 P1090255 1-6 A C1
J 2006 CONNECTOR TMP-S01X-C1 P1091254 7- A C1
JP2001 WIRE ASSY VIO 30 <5>/<5> T9318189 7- A B1
L 2001 CHIP COIL 1.5uH 10% C2520C-1R5K-RA L1690729 1- A I7
L 2002 CHIP COIL 0.56uH C2520C-R56J L1690553 1- A H8
L 2003 M.RFC 33uH LAL03TA330K L1790101 1- A I7
L 2004 M.RFC 2.2uH LAL04NA2R2M L1190319 1-107 A H7
L 2004 M.RFC 2.2uH AL04TB2R2K L1790317 108- A H7
L 2005 RFC WITH BEADS FB-43-5111 L1020015 1- A I4
L 2006 TOROIDAL COIL 41uH 41.00U 3A FR9.5°5 L0021432 1- A H5
L 2007 TOROIDAL COIL 3.67uH 3.67U T68-2 L0022907 1- A D7
L 2008 TOROIDAL COIL 2.24uH 2.24U T68-2 L0022860 1- A D6
L 2009 TOROIDAL COIL 1.89uH 1.89U T68-2 L0022861 1- A D5
L 2010 TOROIDAL COIL 0.96uH 0.96U T68-6 L0022913 1- A D4
L 2011 TOROIDAL COIL 0.84uH 0.84U T68-6 L0022912 1- A D4
L 2012 TOROIDAL COIL 0.43uH 0.43U T68-6 L0022910 1- A D3
L 2013 TOROIDAL COIL 0.27uH 0.27U T68-6 L0022909 1- A D2
L 2019 TOROIDAL COIL 0.27uH 0.27U T68-6 L0022909 1- A C3
L 2021 M.RFC 470uH FLC32T-471J L1690235 1-107 A B1
L 2021 M.RFC 470uH NLV32T-471J-EF L1691805 108- A B1
L 2022 TOROIDAL COIL 2.69uH 2.69U T68-2 L0022859 1- A B7
L 2023 TOROIDAL COIL 2.5uH 2.50U T68-2 L0022908 1- A B6
L 2024 TOROIDAL COIL 1.56uH 1.56U T68-6 L0022915 1- A B5
L 2025 TOROIDAL COIL 1.1uH 1.10U T68-6 L0022914 1- A B4
L 2026 TOROIDAL COIL 0.72uH 0.72U T68-6 L0022911 1- A B4
L 2028 COIL A1 uH 4.5T10.0D1.2UEW-R L0022916 1- A B2
L 2029 M.RFC 470uH FLC32T-471J L1690235 1-107 A B2
L 2029 M.RFC 470uH NLV32T-471J-EF L1691805 108- A B2
P 2001 CONNECTOR IMSA-9206H-T P1090988 1-
P 2002 WIRE ASSY AC051H T9207202A 1-
P 2003 CONNECTOR IMSA-9206H-T P1090988 1-
P 2004 TERMINAL B3 Q6000113 2-
Q 2001 FET RD06HHF1-01 G3090145 1- A I7
Q 2002 TRANSISTOR 2SB1143S G3211430S 1- A G7
Q 2003 IC KIA7808API G1093164 1- A F7
Q 2004 TRANSISTOR DTC124GUA T106 G3070184 1- A G7
Q 2005 IC TA75S01F(TE85R.F) G1091593 1- A G8
Q 2006 TRANSISTOR DTC114TK T146 G3070073 1- A F6
Q 2007 TRANSISTOR 2SC3420-GR(Q) G3334200G 1- A I4
Q 2008 FET RD16HHF1 G3090148 1- A F5
Q 2009 FET RD16HHF1 G3090148 1- A I6
Q 2010 TRANSISTOR DTC124GUA T106 G3070184 1- A F6
Q 2011 TRANSISTOR DTC323TK T146 G3070042 1- A H8
Q 2012 TRANSISTOR SD1405 G3090139 1-14 A F4
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
