Vertex Standard VX-1700 Series User Manual

99VX-1700 Series (EXP Version) Service Manual
PA Unit (Lot 1~108)
Parts List
Q 2012 TRANSISTOR 2SC2879A G3328790A 15- A F4
Q 2013 TRANSISTOR SD1405 G3090139 1-14 A G4
Q 2013 TRANSISTOR 2SC2879A G3328790A 15- A G4
Q 2014 IC TA75S01F(TE85R.F) G1091593 1 A I1
Q 2015 IC LM2904PWR G1094010 1- A E7
R 2001 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1-2 A I7
R 2001 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 3-94 A I7
R 2001 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 95- A I7
R 2002 CHIP RES. 150 1/4W 5% RMC1/4 151JATP J24245151 1- A I8
R 2003 CHIP RES. 150 1/4W 5% RMC1/4 151JATP J24245151 1- A I7
R 2004 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- A H7
R 2005 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G7
R 2006 CHIP RES. 1k 1/4W 5% RMC1/4 102JATP J24245102 1- A G8
R 2007 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 1- A G8
R 2009 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G8
R 2010 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F8
R 2011 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- A G8
R 2012 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 1- A G8
R 2013 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A H6
R 2014 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G8
R 2015 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- A G6
R 2016 CHIP RES. 100 1/2W 5% RK73B2HTTE101J J24279017 1- A G6
R 2017 CHIP RES. 100 1/2W 5% RK73B2HTTE101J J24279017 1- A H6
R 2018 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A G8
R 2019 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A G6
R 2020 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A G6
R 2021 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1 A I6
R 2021 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 2-42 A I6
R 2021 CHIP RES. 390 1/16W 5% RMC1/16 391JATP J24185391 43- A I6
R 2022 METAL FILM RES. 8.2 2W 5% ERX-2SJ8R2P 8.2 J22339020 1- A I6
R 2023 METAL FILM RES. 8.2 2W 5% ERX-2SJ8R2P 8.2 J22339020 1- A J6
R 2024 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A G8
R 2025 METAL FILM RES. 470 3W 5% ERG-3SJ471P 470 J22359019 1- A F6
R 2026 CHIP RES. 1k 1/4W 5% RMC1/4 102JATP J24245102 1- A G6
R 2027 CHIP RES. 1k 1/4W 5% RMC1/4 102JATP J24245102 1- A H6
R 2028 METAL FILM RES. 470 3W 5% ERG-3SJ471P 470 J22359019 1- A I5
R 2029 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A F6
R 2030 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A G8
R 2031 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F6
R 2032 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A G8
R 2033 CHIP RES. 1 1W 5% RMC1 1R0JTE J24305010 1- A G4
R 2034 CHIP RES. 1 1W 5% RMC1 1R0JTE J24305010 1- A G4
R 2035 CHIP RES. 1 1W 5% RMC1 1R0JTE J24305010 1- A H4
R 2036 CHIP RES. 1 1W 5% RMC1 1R0JTE J24305010 1- A H4
R 2037 CHIP RES. 10 1/2W 5% RK73B2HTTE100J J24279005 1- A G4
R 2038 CHIP RES. 10 1/2W 5% RK73B2HTTE100J J24279005 1- A H4
R 2039 METAL FILM RES. 100 3W 5% ERG-3SJ101P 100 J22359023 1- A G5
R 2040 METAL FILM RES. 100 3W 5% ERG-3SJ101P 100 J22359023 1- A H3
R 2041 METAL FILM RES. 100 3W 5% ERG-3SJ101P 100 J22359023 1- A G5
R 2042 METAL FILM RES. 100 3W 5% ERG-3SJ101P 100 J22359023 1- A I4
R 2043 METAL FILM RES. 15 2W 5% ERG-2SJ150P 15 J22339023 1- A H7
R 2044 CHIP RES. 56 1W 5% RMC1 560JTE J24305560 1- A G8
R 2045 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A C1
R 2046 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A B1
R 2047 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E8
R 2048 CHIP RES. 56 1/2W 5% RMC1/2 560JTE J24275560 1- A B1
R 2049 CHIP RES. 56 1/2W 5% RMC1/2 560JTE J24275560 1- A B1
R 2050 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E7
R 2051 CHIP RES. 56 1/2W 5% RMC1/2 560JTE J24275560 1- A B1
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
