MAIN Unit
*** MAIN UNIT ***
PCB with Components CS1573001 TYPE D
PCB with Components CS1573002 TYPE A
PCB with Components CS1573003 TYPE F
Printed Circuit Board FR002190B 1-
Printed Circuit Board FR002190C 4-
Printed Circuit Board FR002190D 7-
Printed Circuit Board FR002190D 10-
C 1001 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B f1
C 1002 CHIP CAP. 4pF 200V CH GRM40CH040C200PT K22230211 1-3 A G1
C 1002 CHIP CAP. 2pF 200V CH GRM40CH020C200PT K22230206 VERSION A 4- A G1
C 1002 CHIP CAP. 4pF 200V CH GRM40CH040C200PT K22230211 VERSION D 4- A G1
C 1002 CHIP CAP. 2pF 200V CH GRM40CH020C200PT K22230206 VERSION F 5- A G1
C 1003 CHIP CAP. 220pF 200V CG C17CG221K6TXLT K22233211 1- B a1
C 1003 CHIP CAP. 220pF 200V CG ATC700B221KW200XT K22233217 27- B a1
C 1004 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f1
C 1005 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A B1
C 1005 AL.ELECTRO.CAP. 3300uF 16V RE3-16V332M 3300UF K40129065 9- A B1
C 1007 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B a2
C 1008 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A A1
C 1009 CHIP CAP. 9pF 200V CH GRM40CH090D200PT K22230215 1-4 B b1
C 1009 CHIP CAP. 9pF 200V CH GRM40CH090D200PT K22230215 VERSION A 5- B b1
C 1009 CHIP CAP. 9pF 200V CH GRM40CH090D200PT K22230215 VERSION D 5- B b1
C 1009 CHIP CAP. 7pF 200V CH GRM40CH070D200PT K22230213 VERSION F 5- B b1
C 1010 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1
C 1011 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1
C 1012 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A H2
C 1013 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b2
C 1014 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1
C 1015 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A G3
C 1016 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1
C 1017 CHIP CAP. 2pF 200V CH GRM40CH020C200PT K22230206 1- B b1
C 1018 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B a3
C 1019 CHIP CAP. 3pF 200V CJ GRM40CJ030C200PT K22230210 VERSION A 4- B b1
C 1019 CHIP CAP. 2pF 200V CH GRM40CH020C200PT K22230206 VERSION F 5- B b1
C 1020 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1
C 1021 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f2
C 1022 CHIP CAP. 2pF 50V CK GRM39CK020C50PT K22174203 1-3 B b1
C 1022 CHIP CAP. 6pF 50V CH GRM39CH060D50PT K22174207 VERSION A 4- B b1
C 1022 CHIP CAP. 2pF 50V CK GRM39CK020C50PT K22174203 VERSION D 4- B b1
C 1022 CHIP CAP. 5pF 50V CH GRM39CH050C50PT K22174206 VERSION F 5- B b1
C 1023 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B g1
C 1024 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b1
C 1025 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B a2
C 1026 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B g1
C 1027 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1-6
C 1029 AL.ELECTRO.CAP. 10uF 16V RC2-16V100M(4X7) K40129012 1- A G2
C 1030 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B a2
C 1031 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B f2
C 1032 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b1
C 1033 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B a2
C 1034 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b2
C 1035 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A B3
C 1036 CHIP CAP. 5pF 200V CH GRM40CH050C200PT K22230207 1-3 A F1
C 1036 CHIP CAP. 6pF 200V CH GRM40CH060D200PT K22230212 VERSION A 4- A F1
C 1036 CHIP CAP. 5pF 200V CH GRM40CH050C200PT K22230207 VERSION D 4- A F1
C 1036 CHIP CAP. 5pF 200V CH GRM40CH050C200PT K22230207 VERSION F 5- A F1
C 1037 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A C3
C 1038 CHIP CAP. 6pF 50V CH GRM39CH060D50PT K22174207 1- B f2
C 1039 CHIP CAP. 0.5pF 50V CK GRM39CK0R5C50PT K22174201 1- B b1
Parts List
REF.
DESCRIPTION VALUE WV TOL. VXSTD P/NMFR’S DESIG VERS.
LAY ADR.
LOT.SIDE.
To Next Page
