MAIN Unit

*** MAIN UNIT ***

PCB with Components CB0370001 TYPE C 1-

PCB with Components CB0370002 TYPE A 6-

Printed Circuit Board FR001570B 1-

Printed Circuit Board FR001570C 5-

Printed Circuit Board FR001570D 19-

C 1001 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B f1

C 1002 CHIP CAP. 8pF 200V CH GRM40CH080D200PT K22230214 1-5 A G1

C 1002 CHIP CAP. 10pF 200V CH GRM40CH100D200PT K22230216 VERSION A 6- A G1

C 1002 CHIP CAP. 8pF 200V CH GRM40CH080D200PT K22230214 VERSION C 6- A G1

C 1003 CHIP CAP. 0.001uF 500V W5R CF316W5R102K500AT K22271802 1- B a1

C 1004 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f1

C 1005 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A B1

C 1005 AL.ELECTRO.CAP. 3300uF 16V RE3-16V332M 3300UF K40129065 18- A B1

C 1006 CHIP CAP. 7pF 200V CH GRM40CH070D200PT K22230213 1-5 B a1

C 1006 CHIP CAP. 8pF 200V CH GRM40CH080D200PT K22230214 VERSION A 6- B a1

C 1006 CHIP CAP. 7pF 200V CH GRM40CH070D200PT K22230213 VERSION C 6- B a1

C 1007 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B a2

C 1008 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A A1

C 1009 CHIP CAP. 33pF 200V CH GRM40CH330J200PT K22230222 1-5 B b1

C 1009 CHIP CAP. 39pF 200V CH GRM40CH390J200PT K22230223 VERSION A 6- B b1

C 1009 CHIP CAP. 33pF 200V CH GRM40CH330J200PT K22230222 VERSION C 6- B b1

C 1010 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1

C 1011 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1

C 1012 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A H2

C 1013 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b2

C 1014 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1

C 1015 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A G3

C 1016 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1

C 1017 CHIP CAP. 2pF 200V CH GRM40CH020C200PT K22230206 VERSION A 6- B b1

C 1018 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B a3

C 1019 CHIP CAP. 18pF 200V CH GRM40CH180J200PT K22230219 1-5 B b1

C 1019 CHIP CAP. 33pF 200V CH GRM40CH330J200PT K22230222 VERSION A 6- B b1

C 1019 CHIP CAP. 18pF 200V CH GRM40CH180J200PT K22230219 VERSION C 6- B b1

C 1020 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1

C 1021 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f2

C 1022 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 1-5 B b1

C 1022 CHIP CAP. 10pF 50V CH GRM39CH100C50PT K22174248 VERSION A 6- B b1

C 1022 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 VERSION C 6- B b1

C 1023 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B g1

C 1024 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b1

C 1025 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B a2

C 1026 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B g1

C 1027 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A G3

C 1029 AL.ELECTRO.CAP. 10uF 16V RC2-16V100M(4X7) K40129012 1- A G2

C 1030 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B a2

C 1031 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B f2

C 1032 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b1

C 1033 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B a2

C 1034 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b2

C 1035 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A B3

C 1036 CHIP CAP. 33pF 200V CH GRM40CH330J200PT K22230222 1-5 A F1

C 1036 CHIP CAP. 22pF 200V CH GRM40CH220J200PT K22230220 VERSION A 6- A F1

C 1036 CHIP CAP. 33pF 200V CH GRM40CH330J200PT K22230222 VERSION C 6- A F1

C 1037 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A C3

C 1038 CHIP CAP. 6pF 50V CH GRM39CH060D50PT K22174207 1- B f2

C 1039 CHIP CAP. 0.5pF 50V CK GRM39CK0R5C50PT K22174201 1- B b1

C 1040 CHIP CAP. 6pF 50V CH GRM39CH060D50PT K22174207 1-3 A B2

C 1041 CHIP CAP. 4pF 50V CH GRM39CH040C50PT K22174205 1-5 A E1

C 1041 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 VERSION A 6- A E1

Parts List

REF.

DESCRIPTION VALUE WV TOL. VXSTD P/NMFR’S DESIG VERS.

LAY ADR.

LOT.SIDE.
