8
Exploded View & Miscellaneous Parts
Å
Å
Å
Å
Å
P1090654
CONNECTOR
RA0060100
CASE
Á
Ä
Ä
Ä
Ä
Ä
À
T9206675
WIRE ASSY
Á
Á
Á
P1090984
CONNECTOR
Ã
Æ
RA0056000
RA005600A (Lot. 4~)
RA005600B (Lot. 6~)
RA00560AB (NTL: Lot. 53~)
RA005600C (Lot. 68~)
RA00560AC (NTL: Lot. 68~)
CHASSIS
Ã
Ã
VR Unit
DISPLAY-2 Unit
Â
Â
MIC Unit
Â
Â
RA001330A
KNOB
R6054387B
SPECIAL NUT
NAME PLATE
RA0013900 (EXPORT)
RA0014000 (VTX(USA))
Å
Å
M4090122
SPEAKER
RA0015600
RUBBER KNOB (40 CHANNEL)
Non-designated parts are available
only as part of a designated assembly.
RA0034900
RUBBER KNOB (4CHANNEL)
DISPLAY-1 Unit
MAIN Unit
U24208001 TAPTITE SCREW M2.6X8 (Lot. 1~5) 1
U20208001 BINDING HEAD SCREW M2.6X8 (Lot. 6~) 1
U20306002 BINDING HEAD SCREW M3X6NI 4
U23205001 TAPTITE SCREW M2.6X5 4
U23206001 TAPTITE SCREW M2.6X6 3
U24306002 TAPTITE SCREW M3X6NI 5
U31206007 OVAL HEAD SCREW M2.6X6B 7
U24308001 TAPTITE SCREW M3X8 1
Description
Qty.
VXSTD P/NREF.
À
Q0000062 FUSE 10A 2
T9021810 DC CABLE 1
Description
Qty.
VXSTD P/N
CP6003001
PANEL-SUB A ASSY
CP6007001
PANEL-SUB B ASSY
Á
Â
Ã
Ä
Å
Æ
To Next Page
