Vertex Standard VX-2000V - Display-2 Unit Parts List

Display-2 Unit
55
*** DISPLAY-2 UNIT ***
PCB with Components CB0383001
Printed Circuit Board FR001590B
D 3002 DIODE 1SS355 TE-17 G2070470 1- B
D 3003 LED TLY211 G2090637 1- A
D 3004 DIODE 1SS355 TE-17 G2070470 1- B
D 3005 DIODE 1SS355 TE-17 G2070470 1- B
D 3006 LED TLG211 G2090343 1- A
D 3007 DIODE 1SS355 TE-17 G2070470 1- B
D 3008 LED TLS211 G2090704 1- A
DS3001 LED GL7S201J G2090488 1- A
JP3001 WIRE ASSY A0953+ T9206687 1-
Q 3001 IC DN8657S-T1 G1092688 1- B
Q 3002 TRANSISTOR XN1213-(TX) G3070194 1- B
Q 3003 TRANSISTOR DTC124EK T146 G3070034 1- B
R 3001 CHIP RES. 680 1/10W 5% RMC1/10T 681J J24205681 1- B
R 3002 CHIP RES. 220 1/10W 5% RMC1/10T 221J J24205221 1- B
R 3003 CHIP RES. 220 1/10W 5% RMC1/10T 221J J24205221 1- B
R 3004 CHIP RES. 220 1/10W 5% RMC1/10T 221J J24205221 1- B
R 3005 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1- B
Parts List
REF.
DESCRIPTION VALUE WV TOL. VXSTD P/NMFR’S DESIG VERS. LAY ADR. LOT.SIDE.
