REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

RF Unit

Parts List

C 1079 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b2

C 1080 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B c4

C 1081 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B g3

C 1082 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- A D3

C 1083 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B g2

C 1084 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B a2

C 1085 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A G2

C 1087 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A F2

C 1088 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A G2

C 1090 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A G2

C 1092 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B e3

C 1093 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- A D4

C 1096 CHIP CAP. 220pF 200V CH GRM40CH221J200PT K22230232 1- A F2

C 1097 CHIP CAP. 0.0022uF 50V B GRM39B222K50PT K22174822 1- A D3

C 1098 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B e3

C 1100 CHIP CAP. 8pF 50V CH GRM39CH080D50PT K22174209 1- A D3

C 1101 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A C2

C 1102 CHIP CAP. 1uF 50V B GRM42-2B105K50PT K22175801 1- A E2

C 1104 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B e4

C 1105 CHIP CAP. 47pF 50V CH GRM39CH470J50PT K22174227 1- A H2

C 1107 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E2

C 1108 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A F2

C 1109 CHIP CAP. 120pF 50V CH GRM39CH121J50PT K22174237 1- A D3

C 1111 CHIP CAP. 47pF 50V CH GRM39CH470J50PT K22174227 1- A H2

C 1112 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E2

C 1113 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 1- A D3

C 1114 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A D2

C 1115 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- B e3

C 1116 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B e2

C 1117 CHIP CAP. 4pF 50V CH GRM39CH040C50PT K22174205 1- A G2

C 1118 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A H2

C 1119 CHIP CAP. 1.5pF 50V CK GRM39CK1R5C50PT K22174258 1- A D3

C 1120 CHIP CAP. 2pF 50V CK GRM39CK020C50PT K22174203 1- A D3

C 1121 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- A D2

C 1122 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A D3

C 1123 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A H3

C 1125 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B e2

C 1126 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- B e3

C 1127 CHIP TA.CAP. 4.7uF 10V TEMSVA1A475M-8R K78100022 1- B d3

C 1128 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A D3

C 1129 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A D3

C 1130 CHIP CAP. 56pF 50V CH GRM39CH560J50PT K22174229 1- A G3

C 1131 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- B d3

C 1132 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A E3

C 1133 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D3

C 1134 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- B c3

C 1135 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B a3

C 1136 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- B e2

C 1137 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D3

C 1138 CHIP CAP. 39pF 50V CH GRM39CH390J50PT K22174225 1- A D3

C 1139 CHIP CAP. 39pF 50V CH GRM39CH390J50PT K22174225 1- A D3

C 1140 CHIP CAP. 8pF 50V CH GRM39CH080D50PT K22174209 1- B c2

C 1141 CHIP TA.CAP. 2.2uF 16V TEMSVA1C225M-8R K78120015 1- B e3

C 1142 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D3

C 1143 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- B e2

C 1144 CHIP CAP. 5pF 50V CH GRM39CH050C50PT K22174206 1- A G3

C 1145 CHIP CAP. 1pF 50V CK GRM39CK010C50PT K22174202 1- A D3

C 1146 CHIP CAP. 4pF 50V CH GRM39CH040C50PT K22174205 1- A G3

C 1147 CHIP CAP. 12pF 50V CH GRM39CH120J50PT K22174213 1- A H3

C 1148 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- B e2

C 1149 CHIP TA.CAP. 2.2uF 6.3V TESVA0J225M1-8R K78080009 1- A E4

C 1150 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1- B e3

C 1151 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A H3

C 1152 CHIP CAP. 2pF 50V CK GRM39CK020C50PT K22174203 1- A D3

C 1153 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A H3

C 1154 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- B e2

C 1155 CHIP CAP. 0.33uF 10V B GRM188B11A334KA01D K22104802 1- A E3

C 1157 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- A F3

C 1158 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A E3

C 1159 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A G3

C 1160 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A H3

C 1161 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B d3

C 1162 CHIP TA.CAP. 33uF 10V TEMSVB21A336M-8R K78100047 1- B b3

C 1163 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- A E3

C 1164 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- B d3

C 1166 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 1- A H3
