Vertex Standard VX-2500EV - Parts List

37
PANEL Unit
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
PCB with Components CB2445001
Printed Circuit Board FR010340B 1-
C 2002 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A A1
C 2003 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B h2
C 2004 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B1
C 2005 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- B f1
C 2006 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- B e1
C 2008 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B h1
C 2009 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B1
C 2010 AL.ELECTRO.CAP. 100uF 16V ECEV1CA101WP K48120012 1- B g2
C 2011 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B g1
C 2012 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 2013 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B h1
C 2014 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B e2
C 2016 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B1
C 2017 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A D2
C 2018 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B g1
C 2019 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B h2
C 2020 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A C1
C 2021 CHIP CAP. 390pF 50V B UMK105B391KW-F K22178824 1- B f2
C 2022 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B c1
C 2023 CHIP CAP. 1uF 10V B GRM40B105K10PT K22100802 1- A B2
C 2024 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B f2
C 2025 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B g2
C 2026 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A B2
C 2027 CHIP CAP. 0.0022uF 50V B UMK105B222KW-F K22178833 1- B f2
C 2028 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B f1
C 2029 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- A B2
C 2030 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B c2
C 2031 CHIP CAP. 0.0018uF 50V B UMK105B182KW-F K22178832 1- B g2
C 2032 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A B2
C 2033 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B g2
C 2034 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2
C 2035 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B f2
C 2036 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- B f2
C 2037 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B g2
C 2038 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A C2
C 2040 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B c1
C 2042 CHIP CAP. 0.0018uF 50V B UMK105B182KW-F K22178832 1- A E1
C 2043 CHIP CAP. 560pF 50V B UMK105B561KW-F K22178826 1- B f2
C 2044 CHIP TA.CAP. 0.33uF 16V TESVSP1C334M-8R K78120029 1- B d2
C 2045 CHIP CAP. 0.22uF 10V B GRM39B224K10PT K22104801 1- A D2
C 2047 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B c1
C 2049 CHIP CAP. 47pF 50V CH UMK105CH470JW-F K22178274 1- B c1
C 2050 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A E1
C 2052 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A E1
C 2053 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B f2
C 2054 CHIP CAP. 680pF 50V B UMK105B681KW-F K22178827 1- B c1
C 2056 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- A E2
C 2057 CHIP CAP. 0.22uF 10V B GRM39B224K10PT K22104801 1- B e2
C 2058 CHIP TA.CAP. 1uF 6.3V TMCP0J105MTR K78080071 1- B c1
C 2059 CHIP TA.CAP. 1uF 6.3V TMCP0J105MTR K78080071 1- B c1
C 2060 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B d2
C 2061 CHIP CAP. 0.1uF 10V BJ LMK105BJ104KV-F K22108806 1- B f2
C 2063 CHIP CAP. 0.22uF 10V B GRM39B224K10PT K22104801 1- B d2
C 2064 CHIP TA.CAP. 2.2uF 6.3V TESVSP0J225M-8R K78080051 1- B d2
C 2065 CHIP TA.CAP. 2.2uF 6.3V TESVSP0J225M-8R K78080051 1- B d2
C 2066 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d1
C 2067 CHIP TA.CAP. 4.7uF 6.3V TESVSP0J475M-8R K78080053 1- B d2
C 2069 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B d1
C 2070 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d1
C 2072 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B d2
C 2073 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B e2
C 2074 CHIP TA.CAP. 3.3uF 10V SKF-1A335M-RP K78100051 1- B c1
C 2075 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B d2
C 2076 CHIP TA.CAP. 6.8uF 6.3V TESVSP0J685M-8R K78080054 1- B e2
C 2077 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B e2
C 2079 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E1
C 2082 CHIP CAP. 15pF 50V CH UMK105CH150JW-F K22178262 1- B d1
C 2083 CHIP CAP. 820pF 50V B UMK105B821KW-F K22178828 1- B c1
C 2085 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B d2
C 2086 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A E1
C 2087 CHIP CAP. 120pF 50V CH UMK105CH121JW-F K22178284 1- B d1
C 2088 CHIP TA.CAP. 22uF 6.3V TEMSVA0J226M-8R K78080047 1- A E1
C 2089 CHIP CAP. 120pF 50V CH UMK105CH121JW-F K22178284 1- B d1
C 2090 CHIP TA.CAP. 1uF 6.3V TMCP0J105MTR K78080071 1- B c2
