Vertex Standard VX-2500EV

To Next Page

To Previous Page

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

RF Unit

Parts List

C 1247 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- A C3

C 1248 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A F4

C 1249 CHIP CAP. 12pF 50V CH GRM39CH120J50PT K22174213 1- B c3

C 1250 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B b3

C 1251 CHIP CAP. 68pF 50V CH GRM39CH680J50PT K22174231 1- A F3

C 1252 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A F3

C 1253 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E1

C 1254 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B b1

C 1255 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B e3

C 1256 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A D1

C 1257 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A E1

C 1258 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A B2

C 1260 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A F1

C 1261 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B f2

C 1262 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A G2

C 1268 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B f3

C 1269 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A D1

C 1270 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B f2

C 1271 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A D1

C 1272 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A E2

C 1273 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A E1

C 1274 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- A E3

C 1277 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- B f3

C 1280 CHIP CAP. 3pF 50V CJ GRM39CJ030C50PT K22174204 1- A H2

C 1282 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B e3

C 1283 CHIP CAP. 10pF 200V CH GRM40CH100D200PT K22230216 1- A F2

C 1285 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A E3

C 1286 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A H2

C 1287 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A F3

C 1288 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E1

C 1289 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B b2

C 1291 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A E1

C 1292 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- B c3

C 1293 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A E4

C 1294 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E1

C 1295 CHIP CAP. 1pF 50V CK GRM39CK010C50PT K22174202 1- A F3

C 1296 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A H1

C 1297 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A C3

C 1298 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- A H2

C 1299 CHIP CAP. 33pF 50V CH GRM39CH330J50PT K22174223 1- A G4

C 1501 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A B1

C 1502 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1

C 1503 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A A1

C 1504 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1

C 1505 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A B1

C 1506 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A B1

C 1507 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A B2

C 1508 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A B2

C 1509 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- A B2

C 1510 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- B g2

C 1511 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A B3

C 1512 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B g2

C 1513 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- A B3

C 1515 AL.ELECTRO.CAP. 10uF 16V RV2-16V100MB55-R K48120014 1- A A1

C 1516 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A B3

C 1517 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A B3

C 1518 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B g2

C 1519 CHIP TA.CAP. 4.7uF 10V TEMSVA1A475M-8R K78100022 1- B f3

C 1520 AL.ELECTRO.CAP. 100uF 16V ECEV1CA101WP K48120012 1- A A2

C 1521 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A A1

C 1523 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B f2

C 1524 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B g2

C 1525 CHIP CAP. 120pF 50V CH GRM39CH121J50PT K22174237 1- A B3

C 1526 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A B3

C 1527 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A B2

C 1528 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A B2

C 1529 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A B3

C 1530 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A B3

C 1531 CHIP CAP. 0.0047uF 50V B GRM39B472K50PT K22174833 1- A B3

C 1532 CHIP CAP. 6pF 50V CH GRM39CH060D50PT K22174207 1- A B2

C 1533 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- A B2

C 1534 CHIP TA.CAP. 68uF 10V TEMSVC1A686M12R K78100048 1- B f1

C 1535 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- A B3

C 1536 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B f3

C 1537 CHIP TA.CAP. 2.2uF 10V TESVA1A225M1-8R K78100021 1- A B3

C 1538 CHIP CAP. 0.0047uF 50V B GRM39B472K50PT K22174833 1- A A3

Vertex Standard VX-2500EV - Page 26
