Vertex Standard VX-2500EV - Page 39

39
PANEL Unit
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
Q 2027 TRANSISTOR 2SC4617 TL R G3346178R 1- B h2
Q 2028 TRANSISTOR PDTC144EE G3070244 1- B h2
Q 2029 IC LC75834W G1093288 1- A C1
Q 2030 FET 2SJ125D-T12-1D G3701257D 1- A D1
Q 2031 FET 2SJ125D-T12-1D G3701257D 1- A D1
Q 2032 FET 2SJ125D-T12-1D G3701257D 1- A D1
Q 2033 TRANSISTOR PDTC144EE G3070244 1- A C1
Q 2034 TRANSISTOR RT1P441U-T11-1 G3070248 1- A C1
Q 2035 TRANSISTOR IMH6A T108 G3070066 1- B g1
Q 2036 TRANSISTOR RT1P441U-T11-1 G3070248 1- B e1
Q 2037 TRANSISTOR RT1P441U-T11-1 G3070248 1- A C1
R 2001 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g2
R 2002 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B g2
R 2003 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A B1
R 2004 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A B1
R 2005 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g2
R 2006 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B h2
R 2008 CHIP RES. 180 1/16W 5% RMC1/16 181JATP J24185181 1- B h1
R 2010 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B h1
R 2011 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A B1
R 2014 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B f1
R 2015 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B g2
R 2017 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B g1
R 2018 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B g1
R 2019 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B g2
R 2020 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B h1
R 2021 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B e1
R 2022 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g1
R 2023 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B h2
R 2024 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A B1
R 2025 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C1
R 2026 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B f1
R 2027 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e2
R 2028 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e2
R 2029 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e2
R 2030 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e2
R 2031 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e2
R 2034 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B h2
R 2035 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 2038 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 1- B g2
R 2039 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B f1
R 2040 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e1
R 2041 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B f1
R 2042 CHIP RES. 20k 1/16W 0.5% RR0510R-203-D J24189150 1- B f1
R 2043 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- B f1
R 2044 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B f1
R 2048 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C1
R 2049 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e1
R 2050 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A1
R 2051 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B f2
R 2052 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f2
R 2053 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B f2
R 2054 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B f2
R 2055 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f2
R 2056 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B g2
R 2057 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B f2
R 2058 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A B2
R 2059 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B c2
R 2060 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c2
R 2061 CHIP RES. 820k 1/16W 5% RMC1/16S 824JTH J24189060 1- B g2
R 2062 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B g2
R 2063 CHIP RES. 180k 1/16W 5% RMC1/16S 184JTH J24189052 1- B g2
R 2064 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B f2
R 2065 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B g2
R 2066 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C2
R 2067 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B g2
R 2068 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B d2
R 2069 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A B2
R 2070 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d1
R 2071 CHIP RES. 1.5M 1/16W 5% RMC1/16S 155JTH J24189063 1- B d2
R 2072 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- A B2
R 2073 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B c1
R 2074 CHIP RES. 180k 1/16W 5% RMC1/16S 184JTH J24189052 1- B c1
R 2075 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B e2
R 2076 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B d1
R 2077 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B c1
