Vertex Standard VX-2500EV - Page 41

41
PANEL Unit
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
R 2189 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B e1
R 2190 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B e1
R 2191 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e1
R 2192 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- B e1
R 2193 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B e1
R 2195 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 2197 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 2- A E2
R 2198 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- B e1
R 2199 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A F1
R 2200 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D2
R 2201 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A G2
R 2202 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f1
R 2203 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B f1
R 2204 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D1
R 2205 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D1
R 2206 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D1
R 2207 CHIP RES. 1.2k 1/16W 5% RMC1/16S 122JTH J24189026 1- A C2
R 2208 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A B2
R 2209 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A C2
R 2210 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D2
R 2211 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E1
R 2212 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E1
R 2213 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E2
R 2214 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A F2
R 2215 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G2
R 2216 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G2
R 2217 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g1
R 2218 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e2
R 2219 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B e2
R 2220 CHIP RES. 1.2k 1/16W 5% RMC1/16 122JATP J24185122 3-
S 2001 TACT SWITCH SKQMAQE010 N5090121 1- A B2
S 2002 TACT SWITCH SKQMAQE010 N5090121 1- A C2
S 2003 TACT SWITCH SKQMAQE010 N5090121 1- A D2
S 2004 TACT SWITCH SKQMAQE010 N5090121 1- A E1
S 2005 TACT SWITCH SKQMAQE010 N5090121 1- A E1
S 2006 TACT SWITCH SKQMAQE010 N5090121 1- A E2
S 2007 TACT SWITCH SKQMAQE010 N5090121 1- A F2
S 2008 TACT SWITCH SKQMAQE010 N5090121 1- A G2
S 2009 TACT SWITCH SKQMAQE010 N5090121 1- A H2
VR2001 POT. V12M4-20A20K-1 J60800260 1- A A1
X 2001 XTAL SX-1319 7.3728MHz 7.3728MHZ H0103275 1- B f1
X 2002 XTAL SX-2204 3.6864MHz 3.6864MHZ H0103249 1- A E1
LCD HOLDER RA0377100 1-
LIGHT GUIDE (LCD) RA0376600 1-
REFLECTOR SHEET RA0381800 1-
DIFFUSER SHEET RA0013600 1-
RUBBER CONNECTOR RA0383700 1-
SPONGE RUBBER (IC) RA0384100 1-
LED SPACER LH-5-5 S6000238 1-
BLIND SHEET (4X3) RA0405200 1-
SHIELD CASE COVER PANEL RA0525300 1-
SPONGE RUBBER RA0525400 1-
