Vertex Standard VX-264 - Controls and Connectors

10
VX-264 Operating Manual
MIC/SP
Jack
(
ExternalMIC/SP
)
controls & connectors
4-ButtonProgrammableKey
LEDIndicator
(
Programmable
)
 Defaultsettingsare:
 SteadyRed: Transmittinginprogress
 BlinkingGreen:BusyChannel
 SteadyGreen: ToneSquelchindefeatedcondition
PTT
Switch
SIDE-1
Button
SIDE-2
Button
SpeakerMicrophone
BatteryPackLatch
AntennaJack
CH

(
Channel
)
Selector
VOL

(
Volume
)
/PWR

(
Power
)
Knob
LCD
(
LiquidCrystalDisplay
)
