4VX-351PMR446 Service Manual
Printed Circuit Board
PCB with Components CS1998702 MAIN-2 UNIT
Mechanical Parts
FRONT CASE ASSY CP9267001
REAR CASE ASSY CP9266001
KNOB VOL RA090600D
KNOB ASSY CH RA091760D
CAP MIC/SP RA0173500
SCREW 1 ps SM3X8SUS RA1424600
BINDING HEAD SCREW 2 pcs M2.6X6B U20206007
BIND HEAD TAPTITE-B 2 pcs M2X10NI U24110002
PAN HEAD TAPTITE-B 7 pcs M2X5NI U44105002
Electrical Parts
SPEAKER 4 ohm A-S0000036-004 4-OHM/1W M4090192B
Main Unit/Main-2 Unit
CD1001, CD2001 CERAMIC DISC JTBM450CX24-A H7901530A B d1
CF1001, CF2001 CERAMIC FILTER LTM450GW-A H3900573A A C1
F 1001, F 2001 CHIP FUSE 3.15A FHC16 322ADTP Q0000118 A C2
MC1001, MC2001 MIC. ELEMENT PF0-1055P M3290045 A C3
Q 1013, Q 2013 FET RD09MUP2(TAPE) G3070367 B b2
S 1001, S 2001 TACT SWITCH SKHLLD N5090066 B a1
S 1002, S 2002 TACT SWITCH SKRTLAE010 N5090130 B b1
S 1003, S 2003 TACT SWITCH SKRTLAE010 N5090130 B c1
S 1005, S 2005 ROTARY SWITCH ED10304O-FB15S7.0-A16-100 N0190195 B a2
SC1001, SC2001 SHIELD CASE (C065) RA0907100 B c3
VR1001, VR2001 POT. RK0971111 20KA/SW J60800256 B a3
X 1001, X 2001 XTAL NX8045GB 7.3728MHz 7.3728MHZ H0103394 A A2
X 1002, X 2002 TCXO 16.8MHz HKE3149A 16.8MHZ H9501060 B d2
XF1001, XF2001 XTAL FILTER MFT50.85P2 50.85MHZ H11023644 B c1
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. SIDE LAY ADR
Parts List
