Vertex VX-6R User Manual

23
CNTL Unit
D 3009 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A A3
D 3010 LED 19-215UYOC/S530-A2/TR8 G2070884 1- A A3
D 3011 LED CL-165HR/YG-D-T G2070860 1- A C3
D 3012 LED CL-191WB-D(TAPE) G2070952 1- A C3
D 3013 DIODE UDZS TE-17 5.1B G2070908 1- B a2
D 3015 DIODE DAN222 TL G2070174 1- B a1
D 3016 DIODE DA221 TL G2070178 1- B a2
D 3017 DIODE DA221 TL G2070178 1- B c1
D 3018 DIODE DA221 TL G2070178 1- B c1
D 3019 DIODE RB751S-40TE61 G2070850 1- B b4
D 3020 DIODE 1SS400 TE61 G2070634 1- B c1
D 3021 DIODE DA221 TL G2070178 1- A A2
D 3022 DIODE RB521S-30 TE61 G2070642 1- B b1
D 3023 DIODE UDZS TE-17 9.1B G2070868 1- B c1
D 3024 DIODE RB751S-40TE61 G2070850 1- B c1
D 3025 DIODE 1SS400 TE61 G2070634 1- B a3
D 3026 DIODE 1SS400 TE61 G2070634 1- B a3
D 3027 DIODE 1SS400 TE61 G2070634 1- B b3
D 3028 DIODE 1SS400 TE61 G2070634 1- B b3
D 3029 DIODE UMP11N TN G2070646 1- B a3
D 3030 DIODE UMP11N TN G2070646 1- B b3
D 3031 DIODE RD2.0UM-T2 G2070190 1- B b2
D 3032 DIODE RB551V-30 TE-17 G2070892 1- B c2
DS3001 LCD AH021M G6090164 1- A B1
J 3001 SHIELD FINGER 2026 3100012 S5000196 1- A B2
J 3002 SHIELD FINGER 2026 3100012 S5000196 1- A B2
J 3003 CONNECTOR 9637S-40-Y905 P1091170 1- B b1
J 3004 CONNECTOR AXK6F10345YP P0091378 1- B b3
L 3001 M.RFC 150uH FLC32P-T-151K L1690661 1- B b4
L 3002 M.RFC 1uH LK1608 1R0K-T L1690687 1- A B2
L 3003 M.RFC 150uH FLC32T-151J L1690229 1- B a1
MC3001 MICROPHONE ELEMENT SKB-2244S-C1033MG M3290040 1- A C2
Q 3001 TRANSISTOR DTC144EE TL G3070075 1- A C3
Q 3002 TRANSISTOR CPH6202-TL G3070265 1- A C2
Q 3003 IC LM2904PWR G1094010 1- B a1
Q 3004 IC LM2902PWR G1094009 1- B a2
Q 3005 TRANSISTOR DTC144EE TL G3070075 1- A C3
Q 3006 TRANSISTOR DTC144EE TL G3070075 1- A C3
Q 3007 TRANSISTOR DTA144EE TL G3070074 1- B a4
Q 3008 IC NJM3403AV-TE1 G1092215 1- B a4
Q 3009 TRANSISTOR 2SC4617 TL R G3346178R 1- B a1
Q 3010 TRANSISTOR DTC144EE TL G3070075 1- B a2
Q 3011 IC M62364FP 600D G1093033 1- B c4
Q 3012 TRANSISTOR DTC144EE TL G3070075 1- B a1
Q 3013 TRANSISTOR DTC144EE TL G3070075 1- B a1
Q 3014 TRANSISTOR DTC144EE TL G3070075 1- B a2
Q 3015 IC LM2904PWR G1094010 1- B c4
Q 3016 IC BU4094BCFV-E2 G1093527 1- B b1
Q 3017 IC NJU7007F2-TE1 G1093617 1- B b4
Q 3018 TRANSISTOR 2SC4617 TL R G3346178R 1- B a1
Q 3019 TRANSISTOR 2SC4617 TL R G3346178R 1- B c2
Q 3020 IC BU2099FV-E2 G1093243 1- B b2
Q 3021 IC NJU7231F30-TE1 G1093512 1- B c1
Q 3022 IC BD4830FVE-TR G1094121 1- B c1
Q 3023 IC BD4830FVE-TR G1094121 1- B c1
Q 3024 IC XC6371A650PR G1094017 1- B b4
Q 3025 TRANSISTOR UMD2N TR G3070076 1- A B2
Q 3026 TRANSISTOR UMW1 TR G3070078 1- B b1
Q 3027 IC TAR5S30(TE85L) G1093570 1- B b1
Q 3028 TRANSISTOR FMMTL718TA G3070335 1- B b1
Q 3028 TRANSISTOR CPH6102-TL G3070223 3- B b1
Q 3029 TRANSISTOR DTC143ZE TL G3070102 1- A A2
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
