RF Unit

*** RF UNIT ***

PCB with Components (with VCO Unit) CP8150002 DST:USA

CP8150003 DST:EXP

CP8150004 DST:EU

CP8150005 DST:AUS

Printed Circuit Board FR012360C 1-

FR012360D 3-

C 1001 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B b1

C 1002 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c1

C 1003 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B b1

C 1004 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- B c1

C 1005 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b1

C 1006 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a1

C 1007 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B a1

C 1008 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a1

C 1009 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1

C 1010 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B a1

C 1011 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- B a1

C 1013 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B b1

C 1014 CHIP CAP. 2pF 50V CK GRM36CK020C50PT K22178204 1- B c1

C 1015 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c1

C 1016 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- B c1

C 1017 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B b1

C 1018 CHIP CAP. 12pF 50V CH GRM36CH120J50PT K22178214 1- B c1

C 1019 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1-2 B c1

C 1019 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 AUSTRALIA 3- B c1

C 1019 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 EUROPE 3- B c1

C 1019 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 EXPORT 3- B c1

C 1019 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 USA 3- B c1

C 1020 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c1

C 1022 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b1

C 1023 CHIP CAP. 68pF 50V CH GRM36CH680J50PT K22178232 1- B a1

C 1024 CHIP CAP. 56pF 50V CH GRM36CH560J50PT K22178230 1- B a1

C 1025 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B a1

C 1026 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1

C 1028 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a1

C 1029 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a1

C 1030 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- B a1

C 1031 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a1

C 1032 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a1

C 1033 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1

C 1034 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1

C 1035 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a2

C 1036 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A A2

C 1037 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a2

C 1038 AL.ELECTRO.CAP. 100uF 16V ECEV1CA101WP K48120012 1- A B2

C 1039 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- B b1

C 1040 CHIP CAP. 1pF 50V CK GRM36CK010B50PT K22178287 1- B b1

C 1041 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c1

C 1042 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B c1

C 1043 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1-2 B b1

C 1043 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 AUSTRALIA 3- B b1

C 1043 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 EUROPE 3- B b1

C 1043 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 EXPORT 3- B b1

C 1043 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 USA 3- B b1

C 1044 CHIP CAP. 8pF 50V CH GRM36CH080D50PT K22178210 1- B c1

C 1045 CHIP CAP. 39pF 50V CH GRM36CH390J50PT K22178226 1- B b1

C 1046 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- B b1

C 1047 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c1

C 1048 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B b1

C 1049 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- B a1

C 1050 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a1

Parts List

DESCRIPTION

VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.

REF.

LOT.

SIDE

LAY ADR.
