CNTL Unit

*** CNTL UNIT ***

PCB with Components CB2944002 DST:USA, TYP:AU2

CB2944003 DST:EXP, TYP:A1

CB2944004 DST:EXP, TYP:A2

CB2944005 DST:EXP, TYP:A3

CB2944006 DST:EU, TYP:B1

CB2944007 DST:EU, TYP:B2

CB2944008 DST:EXP, TYP:B3

CB2944009 DST:EU, TYP:C1

CB2944010 DST:EU, TYP:C2

CB2944011 DST:EXP, TYP:C3

CB2944012 DST:EU, TYP:D1

CB2944013 DST:EU, TYP:D2

CB2944014 DST:AUS, TYP:H1

CB2944015 DST:AUS, TYP:H2

Printed Circuit Board FR012380C 1-

FR012380D 3-

C 3001 CHIP CAP. 1uF 6.3V B GRM39B105K6.3PT K22084801 1- B a2

C 3002 CHIP TA.CAP. 4.7uF 6.3V TESVSP0J475M-8R K78080053 1- B a2

C 3003 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a2

C 3004 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a2

C 3005 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A C3

C 3006 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- B a2

C 3007 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- B a1

C 3009 CHIP CAP. 0.0027uF 50V B UMK105B272KW-F K22178834 1- B a2

C 3010 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a2

C 3011 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a2

C 3012 CHIP TA.CAP. 22uF 4V TEMSVA0G226M-8R K78060023 1- B a2

C 3013 CHIP CAP. 0.022uF 16V B EMK105B223KW-F K22128813 1- B a2

C 3014 CHIP CAP. 0.0047uF 25V B TMK105B472KW-F K22148831 1- B a4

C 3015 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a2

C 3016 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a4

C 3017 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a4

C 3018 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a4

C 3019 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a3

C 3020 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b4

C 3021 CHIP CAP. 1uF 6.3V B GRM39B105K6.3PT K22084801 1- B b4

C 3022 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b4

C 3024 CHIP CAP. 0.015uF 16V B EMK105B153KW-F K22128811 1- B a2

C 3025 CHIP CAP. 150pF 25V CH TMK105CH151JW-F K22148242 1- B a2

C 3026 CHIP CAP. 560pF 50V B UMK105B561KW-F K22178826 1- B a2

C 3027 CHIP CAP. 0.022uF 16V B EMK105B223KW-F K22128813 1- B a2

C 3028 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a4

C 3029 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a4

C 3030 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a4

C 3031 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a4

C 3032 CHIP CAP. 180pF 25V CH TMK105CH181JW-F K22148244 1- B a4

C 3033 CHIP TA.CAP. 22uF 4V TEMSVA0G226M-8R K78060023 1- B a4

C 3034 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a4

C 3035 CHIP CAP. 1uF 6.3V B GRM39B105K6.3PT K22084801 1- B a4

C 3036 CHIP CAP. 1uF 6.3V B GRM39B105K6.3PT K22084801 1- B b4

C 3037 CHIP CAP. 0.015uF 16V B EMK105B153KW-F K22128811 1- B a2

C 3038 CHIP CAP. 150pF 25V CH TMK105CH151JW-F K22148242 1- B a2

C 3039 CHIP CAP. 560pF 50V B UMK105B561KW-F K22178826 1- B a2

C 3040 CHIP CAP. 0.0033uF 50V B GRM36B332K50PT K22178815 1- B a4

C 3041 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a4

C 3042 CHIP CAP. 0.0033uF 50V B UMK105B332KW-F K22178835 1- B a4

C 3044 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b4

C 3045 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b4

C 3046 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B a2

C 3047 CHIP CAP. 1uF 6.3V B GRM39B105K6.3PT K22084801 1- B b4

C 3048 CHIP CAP. 1uF 6.3V B GRM39B105K6.3PT K22084801 1- B a4

DESCRIPTION

VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.

REF.

LOT.

SIDE

LAY ADR.

Parts List
