Vertex VX-6R - Page 51

51
RF Unit
R 1108 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A A1
R 1109 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A A1
R 1110 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A A1
R 1111 CHIP RES. 270 1/16W 5% RMC1/16S 271JTH J24189018 1- A A1
R 1112 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 1113 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 1114 CHIP RES. 10k 1/16W 0.5% MCR01MZPD1002 J24189374 1- A B2
R 1115 CHIP RES. 10k 1/16W 0.5% MCR01MZPD1002 J24189374 1- A B2
R 1116 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b1
R 1117 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b1
R 1118 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 1119 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 1120 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c1
R 1121 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B a2
R 1124 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b1
R 1125 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A B1
R 1126 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1-2 B a1
R 1126 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 AUSTRALIA 3- B a1
R 1126 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 EXPORT 3- B a1
R 1126 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 USA 3- B a1
R 1128 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A B1
R 1129 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- A B1
R 1129 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 3- A B1
R 1130 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 3- B b1
R 1131 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 USA 2-
R 1132 CHIP RES. 470 1/10W 5% RMC1/10T 471J J24205471 USA 2-
TH1001 THERMISTOR ERTJ0EV473J G9090120 1- B b2
X 1001 XTAL XVNBAI 11.7MHz 11.7MHz H0103311 1- B c2
TERMINAL PLATE RA0287100 1-
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
