24
VX-920/-920E VHF series Service Manual
Main Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Parts List
C 1046 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g3
C 1047 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- B g3
C 1048 CHIP CAP. 5pF 5 0V CH GRM1552C1H5R0CZ01D K22178207 1- A C1
C 1049 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A2
C 1049 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A A2
C 1050 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B2
C 1051 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B h3
C 1052 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A A3
C 1053 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B g2
C 1054 CHIP CAP. 82pF 50V CH GRM1882C1H820JA01D K22174233 1- B g3
C 1055 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B f3
C 1056 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1-4 B f3
C 1057 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A G2
C 1057 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A G2
C 1059 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B3
C 1059 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A B3
C 1060 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B h2
C 1060 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B h2
C 1061 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 18- B f3
C 1061 CHIP CAP. 56pF 50V CH GRM1882C1H560JA01D K22174229 22- B f3
C 1061 CHIP CAP. 68pF 50V CH GRM1882C1H680JA01D K22174231 25- B f3
C 1062 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f3
C 1063 CHIP CAP. 0.001uF
50V B GRM155B11H102KA01D K22178809 1- B f3
C 1065 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B3
C 1065 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A B3
C 1066 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1-7 A A3
C 1066 CHIP TA.CAP. 4.7uF 6.3V TEESVA0J475M8R K78080017 IS VERS 8- A A3
C 1066 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 NON IS 8- A A 3
C 1067 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A C1
C 1068 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A A3
C 1069 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B g2
C 1070 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- A D1
C 1073 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C1
C 1073 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A C1
C 1074 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A B2
C 1075 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A B2
C 1076 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B3
C 1077 CHIP TA.CAP. 4.7uF 20V TEESVA1D475M8R K78130048 1- A C2
C 1078 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1-3 A D3
C 1079 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B h2
C 1080 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A H1
C 1081 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A B2
C 1082 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A B3
C 1083 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C2
C 1083 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A C2
C 1084 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D3
C 1085 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C3
C 1086 CHIP CAP. 0.0018uF 50V B GRM155B11H182KA01D K22178812 1- A H1
C 1087 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A D1
C 1088 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B g2
C 1089 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1-7 A B2
C 1089 CHIP TA.CAP. 4.7uF 6.3V TEESVA0J475M8R K78080017 IS VERS 8- A B2
C 1089 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 NON IS 8- A B2
C 1091 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A H1
C 1092 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2
C 1093 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2
C 1094 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- A B3
C 1095 CHIP CAP. 6pF 5 0V CH GRM1552C1H6R0DZ01D K22178208 1- B h3
C 1096 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B f3
C 1097 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A B2
C 1098 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g2
