25
VX-920/-920E VHF series Service Manual
Main Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
Parts List
C 1099 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B3
C 1100 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A A3
C 1101 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B2
C 1104 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A H3
C 1107 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A H3
C 1107 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A H3
C 1109 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A E3
C 1110 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2
C 1112 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A H3
C 1113 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E3
C 1113 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A E3
C 1114 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B h2
C 1115 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B h2
C 1116 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e3
C 1117 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E3
C 1118 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- B e3
C 1119 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A H1
C 1120 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e3
C 1121 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e1
C 1121 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B e1
C 1122 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A B4
C 1123 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D3
C 1124 CHIP CAP. 0.001uF
50V B GRM155B11H102KA01D K22178809 1-21 A D3
C 1125 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 3 A B4
C 1127 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A H1
C 1128 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- A H1
C 1129 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- A H2
C 1130 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B h2
C 1130 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B h2
C 1131 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- A H1
C 1132 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B e3
C 1132 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 3- B e3
C 1133 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1-17 A D3
C 1134 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1-3 A D3
C 1135 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B g1
C 1135 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 41- B g1
C 1136 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A H1
C 1139 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- A H2
C 1140 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B g1
C 1141 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A B3
C 1141 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A B3
C 1142 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I2
C 1142 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A I2
C 1143 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B g1
C 1144 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- A H1
C 1145 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g1
C 1146 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B g1
C 1147 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D3
C 1147 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 4- A D3
C 1148 CHIP CAP. 0.0018uF 50V B GRM155B11H182KA01D K22178812 1- A G3
C 1150 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- A D3
C 1151 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- A G3
C 1152 CHIP CAP. 8pF 5 0V CH GRM1552C1H8R0DZ01D K22178210 1- B d3
C 1153 CHIP CAP. 2pF 5 0V CK GRM1554C1H2R0CZ01D K22178204 1- A E3
C 1155 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A C2
C 1156 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A G4
C 1156 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A G4
C 1158 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G3
C 1160 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- B d3
C 1161 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B g1
C 1162 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A C2
