VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
C 1163 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A C2
C 1164 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A H1
C 1164 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A H1
C 1165 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F3
C 1166 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B h1
C 1167 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1 B e3
C 1167 CHIP CAP. 330pF 50V B GRM155B11H331KA01D K22178803 2 B e3
C 1167 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 3- B e3
C 1168 CHIP CAP. 0.0033uF 50V B GRM155B11H332KA01D K22178815 1- A G4
C 1169 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g1
C 1171 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1
C 1171 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B a1
C 1172 CHIP TA.CAP. 10uF 6.3V TEESVP0J106M8R K78080055 1- A F3
C 1174 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G4
C 1175 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E3
C 1175 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A E3
C 1176 CHIP CAP. 2pF 5 0V CK GRM1554C1H2R0CZ01D K22178204 1- A E3
C 1177 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1
C 1177 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B a1
C 1180 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f3
C 1183 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B g1
C 1183 CHIP CAP. 39pF
50V CH GRM1552C1H390JZ01D K22178226 41- B g1
C 1184 CHIP CAP. 0.22uF 10V B GRM155B31A224KE18D K22108808 1- A G4
C 1185 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f2
C 1186 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B a3
C 1186 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 39- B a3
C 1187 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B f3
C 1187 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B f3
C 1188 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b3
C 1189 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A G4
C 1189 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A G4
C 1190 CHIP CAP. 330pF 50V B GRM155B11H331KA01D K22178803 1- B a1
C 1191 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B a3
C 1192 CHIP CAP. 68pF 50V CH GRM1552C1H680JZ01D K22178232 1- B b3
C 1193 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1194 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1-3 B b3
C 1194 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 4- B b3
C 1194 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 39- B b3
C 1195 CHIP CAP. 0.0012uF 50V B GRM155B11H122KA01 K22178810 1- B a3
C 1197 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B f2
C 1197 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 4- B f2
C 1198 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A D2
C 1200 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g1
C 1200 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B g1
C 1201 CHIP TA.CAP. 4.7uF 6.3V TEESVA0J475M8R K78080017 1- B f1
C 1203 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2
C 1204 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1
C 1204 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B a1
C 1206 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g1
C 1207 CHIP CAP. 120pF 50V CH GRM1552C1H121JA01D K22178238 1- B b3
C 1208 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2
C 1209 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1
C 1209 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B a1
C 1210 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b1
C 1210 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B b1
C 1211 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 1-41 B a3
C 1211 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 42- B a3
C 1212 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D2
C 1213 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B f1
C 1213 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B f1
C 1215 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 1- A H3
