27
VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
C 1216 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e2
C 1216 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B e2
C 1217 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1218 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- B b3
C 1219 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1220 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B a1
C 1222 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B f1
C 1222 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B f1
C 1223 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c1
C 1223 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B c1
C 1224 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B e2
C 1225 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1
C 1226 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1-41 B a3
C 1226 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 42- B a3
C 1227 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B f1
C 1227 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B f1
C 1228 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B f2
C 1229 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2
C 1230 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A D2
C 1231 CHIP CAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 1- A H3
C 1232 CHIP CAP. 330pF 50V B GRM155B11H331KA01D K22178803 1- B a1
C 1233 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023
1- B b3
C 1234 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A H3
C 1234 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 39- A H3
C 1235 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1236 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b1
C 1236 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B b1
C 1237 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1239 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A D2
C 1240 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2
C 1241 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B f2
C 1242 CHIP TA.CAP. 4.7uF 6.3V TMCMA0J475MTR K78080026 1- B a3
C 1244 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- A H3
C 1246 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1247 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B f2
C 1248 CHIP CAP. 3pF 50V CJ GRP1553C1H3R0CZ01E K22178205 1- B e2
C 1249 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b1
C 1249 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B b1
C 1250 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- A H2
C 1252 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B e2
C 1253 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B f1
C 1253 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B f1
C 1254 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b1
C 1254 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B b1
C 1256 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a1
C 1257 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B g2
C 1258 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B f2
C 1259 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G2
C 1260 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- A H2
C 1262 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B e2
C 1264 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2
C 1265 CHIP CAP. 680pF 50V B GRM155B11H681KA01D K22178807 1- B b1
C 1266 CHIP CAP. 180pF 25V CH GRM1552C1E181JA01D K22148201 1- B b1
C 1266 CHIP CAP. 180pF 50V CH GRM1552C1H181JA01D K22179711 39- B b1
C 1267 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- A H2
C 1268 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1
C 1269 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2
C 1270 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e1
C 1270 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B e1
C 1271 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1
C 1273 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e2
