VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
C 1273 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B e2
C 1274 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1-41 B e2
C 1274 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 42- B e2
C 1276 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B e1
C 1277 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- B e2
C 1280 CHIP CAP. 1pF 5 0V CK GRM1554C1H1R0BZ01D K22178287 1- B e2
C 1281 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e2
C 1282 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3
C 1282 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B d3
C 1283 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BZ01D K22178288 1- B e2
C 1284 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e3
C 1286 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B e2
C 1286 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 35- B e2
C 1287 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B e2
C 1288 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e3
C 1289 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d3
C 1290 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2
C 1291 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e3
C 1291 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B e3
C 1292 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B e1
C 1294 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B e3
C 1294 CHIP CAP. 15pF
50V CH GRM1552C1H150JZ01D K22178216 35- B e3
C 1295 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A A1
C 1296 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2
C 1297 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B e2
C 1297 CHIP CAP. 39pF 50V CH GRM1552C1H390JZ01D K22178226 35- B e2
C 1298 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B e2
C 1298 CHIP CAP. 39pF 50V CH GRM1552C1H390JZ01D K22178226 35- B e2
C 1299 CHIP CAP. 7pF 5 0V CH GRM1552C1H7R0DZ01D K22178209 1- B d3
C 1300 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2
C 1301 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d4
C 1302 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B f2
C 1303 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B d2
C 1304 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d3
C 1305 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A A1
C 1306 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e3
C 1308 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B d2
C 1311 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d4
C 1312 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B e1
C 1313 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B e2
C 1314 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1
C 1315 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B d3
C 1316 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2
C 1317 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3
C 1318 CHIP CAP. 4pF 5 0V CH GRM1552C1H4R0CZ01D K22178206 1- B d3
C 1320 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1
C 1320 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B d1
C 1321 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B d3
C 1322 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3
C 1322 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B d3
C 1323 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d2
C 1324 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2
C 1324 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B d2
C 1325 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- A F3
C 1326 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- A G3
C 1327 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A G2
C 1328 CHIP CAP. 5pF 5 0V CH GRM1552C1H5R0CZ01D K22178207 1- B d3
C 1329 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c2
C 1330 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G2
C 1331 CHIP CAP. 0.033uF 10V B GRM155B11A333KA01D K22108803 1- B d2
C 1332 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B d3
