VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
C 1333 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A E1
C 1334 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A F2
C 1335 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G2
C 1336 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B d1
C 1337 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E1
C 1337 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A E1
C 1338 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G2
C 1339 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E1
C 1340 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A E2
C 1341 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1
C 1343 CHIP CAP. 8pF 5 0V CH GRM1552C1H8R0DZ01D K22178210 1- B d3
C 1344 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E1
C 1344 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A E1
C 1345 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A G2
C 1345 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A G2
C 1346 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B d3
C 1347 CHIP CAP. 180pF 25V CH GRM1552C1E181JA01D K22148201 1- B c2
C 1347 CHIP CAP. 180pF 50V CH GRM1552C1H181JA01D K22179711 39- B c2
C 1348 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F2
C 1348 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A F2
C 1349 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E2
C 1349 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 16- A E2
C 1350 CHIP CAP. 0.01uF
16V B GRM36B103K16PT K22128804 1- B c3
C 1350 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B c3
C 1351 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E1
C 1352 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G2
C 1353 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1
C 1353 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B d1
C 1354 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c3
C 1355 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F2
C 1356 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B d2
C 1357 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B d3
C 1358 CHIP TA.CAP. 0.68uF 35V TEESVA1V684M8R K78160030 1- B c3
C 1359 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c3
C 1360 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A E1
C 1361 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A G2
C 1362 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E2
C 1362 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 28- A E2
C 1364 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3
C 1364 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B d3
C 1365 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c1
C 1365 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B c1
C 1366 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 1- B c1
C 1367 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2
C 1368 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1
C 1368 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B d1
C 1369 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c3
C 1370 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c2
C 1371 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- A E1
C 1372 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c4
C 1372 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B c4
C 1373 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1374 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1375 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 1- B d2
C 1375 CHIP CAP. 68pF 50V CH GRM1552C1H680JZ01D K22178232 83- B d2
C 1376 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c2
C 1377 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c4
C 1379 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E1
C 1379 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- A E1
C 1380 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c3
C 1381 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c4
