30
VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
C 1382 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c3
C 1383 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- B c2
C 1383 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 4- B c2
C 1383 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 39- B c2
C 1384 CHIP CAP. 270pF 50V B GRM155B11B271KD01D K22178802 1- B c2
C 1384 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 4- B c2
C 1384 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 39- B c2
C 1385 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 1- B c2
C 1385 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 4- B c2
C 1387 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B c1
C 1388 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c1
C 1388 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B c1
C 1390 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d1
C 1391 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c1
C 1392 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c2
C 1392 CHIP CAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 4- B c2
C 1393 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B c4
C 1394 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B c3
C 1395 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B c3
C 1396 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1397 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c3
C 1399 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c4
C 1400 CHIP CAP. 33pF
50V CH GRM1552C1H330JZ01D K22178224 1- B c3
C 1401 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c3
C 1402 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B c3
C 1403 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2
C 1403 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B d2
C 1404 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B c1
C 1405 CHIP CAP. 10uF 6.3V B JMK212BJ106KG-T K22080802 1- B c2
C 1406 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A F1
C 1407 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c1
C 1408 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c1
C 1408 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B c1
C 1409 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c1
C 1409 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B c1
C 1410 CHIP CAP. 560pF 50V B GRM155B11H561KA01D K22178806 1- B c1
C 1412 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A F1
C 1413 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G1
C 1414 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c1
C 1414 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B c1
C 1415 CHIP CAP. 10uF 6.3V B JMK212BJ106KG-T K22080802 1- A F3
C 1416 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B e3
C 1417 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a1
C 1417 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B a1
C 1418 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- A G1
C 1423 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2
C 1428 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G2
C 1429 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D1
C 1430 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D1
C 1432 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g1
C 1434 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- A C1
C 1437 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2
C 1438 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B e3
C 1438 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 4- B e3
C 1438 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 39- B e3
C 1439 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B c1
C 1440 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 2- B g3
C 1440 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 4- B g3
C 1440 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 25- B g3
C 1443 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 2- A B1
C 1443 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 4- A B1
