VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
Main Unit
Parts List
C 1451 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 4-
CD1001 CERAMIC DISC ECDA450C24 H7901460 1- B d2
CF1001 CERAMIC FILTER ELFY450E H3900549 1- B d1
CF1002 CERAMIC FILTER ELFC450G H3900538 1-3 B d1
CF1002 CERAMIC FILTER ELFC450G H3900538 4- B d1
D 1001 DIODE PTZ TE25 15A G2070692 1- A C1
D 1002 DIODE 1SS400 TE61 G2070634 1- A A3
D 1003 DIODE 1SS400 TE61 G2070634 1- A A4
D 1004 DIODE 1SS400 TE61 G2070634 1- A D4
D 1005 DIODE 1SS400 TE61 G2070634 1- A E4
D 1006 DIODE DA221 TL G2070178 1- A B1
D 1007 DIODE DA221 TL G2070178 1- A B2
D 1008 DIODE DA221 TL G2070178 1- A B2
D 1009 DIODE DA221 TL G2070178 1- A B2
D 1010 DIODE DA221 TL G2070178 1- A B2
D 1011 DIODE HVU131 TRF-E G2070462 1- B g3
D 1012 DIODE HVU131 TRF-E G2070462 1- B g3
D 1013 DIODE DA221 TL G2070178 1- A B2
D 1014 DIODE 1SV323(TPH3.F) G2071006 1- B g2
D 1015 DIODE 1SV323(TPH3.F) G2071006 1- B h2
D 1016 DIODE 1SS400 TE61 G2070634 1- A B3
D 1017 DIODE 1SS400 TE61 G2070634 1- B g2
D 1018 DIODE 1SV323(TPH3.F) G2071006 1- B h1
D 1019 DIODE 1SV323(TPH3.F) G2071006 1- B g1
D 1020 DIODE DAN222 TL G2070174 1- B f2
D 1021 DIODE 1SS400 TE61 G2070634 1- A D2
D 1022 DIODE DA221 TL G2070178 1- A D2
D 1023 DIODE DA221 TL G2070178 1- B a1
D 1024 DIODE DAN235E TL G2070612 1- B f1
D 1027 DIODE 1SV286(TPH3.F) G2070610 1- B e2
D 1028 LED SDDF01000A1 G2071056 1- A A1
D 1028 LED FRGB1315C-11-TF G2071166 32- A A1
D 1028 LED ARGB1315C-TF G2071264 47- A A1
D 1029 DIODE 1SS400 TE61 G2070634 1- B e2
D 1030 DIODE 1SV282(TPH3.F) G2070778 1- B d2
D 1031 DIODE 1SV282(TPH3.F) G2070778 1- B d2
D 1032 DIODE 1SV282(TPH3.F) G2070778 1- B d2
D 1033 DIODE 1SV286(TPH3.F) G2070610 1- B d2
D 1034 DIODE 1SV286(TPH3.F) G2070610 1- B d2
D 1035 DIODE 1SV282(TPH3.F) G2070778 1- B d2
D 1036 DIODE 1SV286(TPH3.F) G2070610 1- B d2
D 1037 DIODE 1SV286(TPH3.F) G2070610 1- B d2
D 1038 DIODE 1SS400 TE61 G2070634 1- A E1
D 1039 DIODE DA221 TL G2070178 1- B d1
D 1040 DIODE DA221 TL G2070178 1- A E2
D 1041 DIODE HZU5ALL-TRF-E G2070754 1- A E1
D 1042 DIODE 1SS400 TE61 G2070634 1- A F2
D 1043 DIODE DAN235E TL G2070612 1- B c3
D 1044 DIODE DAN222 TL G2070174 1- B d1
D 1045 DIODE 1SS400 TE61 G2070634 1- B c3
D 1046 DIODE DAN222 TL G2070174 1- B d1
D 1047 DIODE DA221 TL G2070178 1- B c1
D 1048 DIODE DA221 TL G2070178 1- B c1
D 1049 DIODE 1SV323(TPH3.F) G2071006 1- B g2
D 1050 DIODE 1SV323(TPH3.F) G2071006 1- B h2
D 1051 DIODE 1SV323(TPH3.F) G2071006 1- B g1
D 1052 DIODE 1SV323(TPH3.F) G2071006 1- B h1
D 1053 DIODE EDZ TE-61 3.9B G2071004 3-
D 1054 DIODE EDZ TE-61 5.1B G2070998 28-
F 1001 CHIP FUSE 3A 0434 003. 3.0A Q0000107 1-20 A C2
F 1001 CHIP FUSE 3A 0434 003. 3.0A Q0000107 IS VERS 21- A C2
