32
VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
F 1001 CHIP FUSE 3.15A FHC16 322ADTP Q0000118 NON IS 21- A C2
FB1001 FERRITE BEADS SMB304729 L9190094 1- B g3
FB1002 FERRITE BEADS BLM21A121SPT L9190108 1- B e3
HS1001 HEATSINK PLATE RA0697800 1- B f3
J 1001 CONNECTOR 9639S-24B-Y905 P1091222 1- A B1
J 1002 SPRING CONNECTOR R0152490 1- B h3
J 1003 CONNECTOR AXK6S40535P P0091209 1-3 B a2
J 1003 CONNECTOR AXK6S40535P P0091209 4- B a2
J 1004 CONNECTOR AXN320C130P P1090924 1- B g2
J 1005 CONNECTOR 9637S-08A-Y905 P1091221 1- A G1
J 1006 CONNECTOR U.FL-R-SMT(10) P1091155 1- B h3
L 1001 COIL 0.014uH AS050425-14NJ L0022827 1- B h3
L 1002 COIL 0.047uH AS030821-47NJ L0022824 1- B h3
L 1003 COIL 0.047uH AS030821-47NJ L0022824 1- B g3
L 1004 COIL 0.047uH AS030821-47NK L0022588 1- B g3
L 1005 COIL 0.033uH AS030621-33NJ L0022822 1- B g3
L 1006 M.RFC 0.047uH 2% C1608CB-47NG-RF L1691040 1- B g3
L 1007 M.RFC 0.39uH 2% C1608CB-R39G-RF L1691107 1- B g3
L 1008 M.RFC 2.7uH LK1608 2R7K-T L1690848 1- A B3
L 1009 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B h3
L 1010 M.RFC 2.7uH LK1608 2R7K-T L1690848 1- A B3
L 1011 COIL 0.0054uH AS050321-5R4NJ L0022581 1- B f3
L 1012 COIL 0.047uH AS030821-47NK L0022588 1- B f3
L 1013 CHIP COIL 0.068uH LQW2BHN68NJ03L L1690605 1- B h2
L 1014 CHIP COIL 0.068uH LQW2BHN68NJ03L L1690605 1- B h2
L 1015 COIL 0.025uH AS030521-25NJ L0022821 1- B g3
L 1019 COIL 0.025uH AS030521-25NJ L0022821 1- B e3
L 1020 M.RFC 6.8uH LK1608 6R8K-T L1690632 1- B h2
L 1023 CHIP COIL 0.068uH LQW2BHN68NJ03L L1690605 1- B h1
L 1024 M.RFC 0.056uH HK1608 56NJ-T L1690525 1- B e3
L 1024 M.RFC 0.068uH HK1608 68NJ-T L1690526 3 B e3
L 1024 M.RFC 0.056uH HK1608 56NJ-T L1690525 4- B e3
L 1025 CHIP COIL 0.068uH LQW2BHN68NJ03L L1690605 1- B h1
L 1026 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B f2
L 1027 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B f2
L 1028 M.RFC 1uH LK1608 1R0K-T L1690687 1- B b3
L 1029 M.RFC 1uH LK1608 1R0K-T L1690687 1- B b3
L 1030 M.RFC 1uH LK1608 1R0K-T L1690687 1- B f1
L 1031 M.RFC 0.047uH HK1608 47NJ-T L1690524 1- B f2
L 1032 M.RFC 0.056uH HK1608 56NJ-T L1690525 1- B f2
L 1033 M.RFC 0.047uH HK1608 47NJ-T L1690524 1- B f2
L 1034 M.RFC 100uH FLC32T-101J L1690227 1- A H3
L 1035 M.RFC 0.056uH HK1608 56NJ-T L1690525 1- B g1
L 1036 M.RFC 0.047uH HK1608 47NJ-T L1690524 1- B e2
L 1037 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B e2
L 1038 M.RFC 0.56uH LK1608 R56K-T L1690415 1- B e1
L 1039 M.RFC 1uH LK1608 1R0K-T L1690687 1- B e2
L 1040 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B e2
L 1041 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B d2
L 1043 COIL 0.051uH ASF030821-51R0NJ L0022878 1- B d2
L 1044 M.RFC 1uH LK1608 1R0K-T L1690687 1- B d4
L 1045 COIL 0.0418uH ASF030721-41R8NJ L0022877 1- B d2
L 1046 M.RFC 0.39uH 2% C1608CB-R39G-RF L1691107 1- B d2
L 1047 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B d3
L 1049 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B d2
L 1050 M.RFC 0.039uH HK1608 39NJ-T L1690523 1- B d3
L 1051 M.RFC 0.039uH HK1608 39NJ-T L1690523 1- B d3
L 1052 M.RFC 1uH LK1608 1R0K-T L1690687 1- B d1
L 1053 M.RFC 0.39uH 2% C1608CB-R39G-RF L1691107 1- B d2
L 1054 M.RFC 0.39uH 2% C1608CB-R39G-RF L1691107 1- B d2
L 1055 M.RFC 0.039uH HK1608 39NJ-T L1690523 1- B d3
