33
VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
L 1056 M.RFC 33uH FLC32T-330J L1690221 1- A F3
L 1057 M.RFC 0.15uH HK1608 R15J-T L1690938 1- B c1
Q 1001 IC CD4053BPWR G1093864 1- A C1
Q 1001 IC NJU4053BV-TE1 G1092927 3- A C1
Q 1002 TRANSISTOR XP1501-(TX) G3070143 1- A A3
Q 1003 TRANSISTOR 2SB1132 T100 R G3211327R 1- A A3
Q 1004 TRANSISTOR DTC144EE TL G3070075 1- A A3
Q 1005 IC TAR5S50U(TE85L.F) G1094097 1- A B3
Q 1006 TRANSISTOR UMD5N TR G3070343 1- B e1
Q 1007 FET RTQ030P02 G4070015 1- A C2
Q 1008 IC TDA2822D013TR G1091542 1- A A2
Q 1009 TRANSISTOR DTC114TE TL G3070225 1- A B4
Q 1010 FET 2SK3476(TE12L.Q) G3834768 1- A C3
Q 1011 TRANSISTOR UMD12N TR G3070342 1- A B2
Q 1012 TRANSISTOR 2SA1774 TL R G3117748R 1- A C2
Q 1013 TRANSISTOR DTC114TE TL G3070225 1- A B2
Q 1014 TRANSISTOR UMD12N TR G3070342 1- A B2
Q 1015 IC TDA2822D013TR G1091542 1- A B2
Q 1016 IC CD4053BPWR G1093864 1- A H1
Q 1016 IC NJU4053BV-TE1 G1092927 3- A H1
Q 1017 TRANSISTOR DTC144EE TL G3070075 1- A C3
Q 1018 TRANSISTOR DTC144EE TL G3070075 1- A C2
Q 1019 TRANSISTOR DTC144EE TL G3070075 1- A A4
Q 1020 IC M62364FP 600D G1093033 1- A E3
Q 1021 FET 2SK3475(T2LVX.F) G3070318 1- B e3
Q 1022 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- B g2
Q 1023 IC LA8630M-B-TLM-E G1093452 1- A H2
Q 1024 TRANSISTOR DTC144EE TL G3070075 1- A D3
Q 1025 IC CD4052BPWR G1093862 1- A H2
Q 1026 TRANSISTOR UNR911FJ0L G3070349 1- A H1
Q 1027 TRANSISTOR 2SC3356-T2B R25 G3333567E 1- B d3
Q 1028 IC BD6111FV-E2 G1093746 1- A C2
Q 1029 IC CD4052BPWR G1093862
1- A G3
Q 1030 IC NJU4053BV-TE1 G1092927 1- A F3
Q 1031 IC NJM2130F-TE1 G1093074 1- A D2
Q 1032 IC AK2345CP-E2 G1093184 1- B a3
Q 1033 TRANSISTOR 2SC5226-4-TL G3352268D 1- B e2
Q 1034 IC SPM5001-TL-E G1093686 1- B f1
Q 1034 IC SPM5002-TL-E G1094899 73- B f1
Q 1035 TRANSISTOR DTC144EE TL G3070075 1- B e2
Q 1036 TRANSISTOR 2SA1774 TL R G3117748R 1- A D2
Q 1037 TRANSISTOR DTC144EE TL G3070075 1- B b1
Q 1038 TRANSISTOR DTA144EE TL G3070074 1- B e3
Q 1039 TRANSISTOR DTC114TE TL G3070225 1- A H3
Q 1040 TRANSISTOR DTC114TE TL G3070225 1- B e2
Q 1041 IC BU8872FS-E2 G1093656 1- A H2
Q 1042 TRANSISTOR 2SC5226-4-TL G3352268D 1- B e2
Q 1043 TRANSISTOR DTC144EE TL G3070075 1- B e1
Q 1044 TRANSISTOR DTC144EE TL G3070075 1- B e2
Q 1045 TRANSISTOR UNR911FJ0L G3070349 1- B d3
Q 1046 TRANSISTOR DTC114TE TL G3070225 1- A A3
Q 1047 FET 2SK508-T2B K52 A G3805087B 1- B e2
Q 1048 TRANSISTOR DTC114TE TL G3070225 1- B e2
Q 1048 TRANSISTOR DTC143EE TL G3070114 41- B e2
Q 1049 TRANSISTOR DTC144EE TL G3070075 1- B d3
Q 1050 TRANSISTOR DTC114TE TL G3070225 1- A A3
Q 1051 TRANSISTOR 2SC5226-4-TL G3352268D 1- B d3
Q 1052 TRANSISTOR 2SC4227-T2 R32 G3342277B 1- B e2
Q 1052 TRANSISTOR 2SC4227-T1 R32 G3342278B 3- B e2
Q 1053 TRANSISTOR DTC114TE TL G3070225 1- A A2
Q 1054 TRANSISTOR DTC114TE TL G3070225 1- A A2
