VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
Q 1055 TRANSISTOR 2SD1767 T100 Q G3417677Q 1- A A1
Q 1056 TRANSISTOR 2SC4617 TL R G3346178R 1- B e3
Q 1057 TRANSISTOR DTC114TE TL G3070225 1- A A2
Q 1058 TRANSISTOR 2SC5226-4-TL G3352268D 1- B d1
Q 1059 TRANSISTOR DTC114TE TL G3070225 1- A A2
Q 1060 TRANSISTOR UMD5N TR G3070343 1- B d1
Q 1061 IC S-80835CNMC-B8U-T2-G G1093606 1- A E2
Q 1062 IC TAR5S35U(TE85L.F) G1094096 1- A G2
Q 1063 IC TAR5S35U(TE85L.F) G1094096 1- A E1
Q 1064 TRANSISTOR DTC114TE TL G3070225 1- A F3
Q 1065 IC BR93L66RFVM-WTR G1093874 1-3 A G2
Q 1065 IC BR93L66RFVM-WTR G1093874 4- A G2
Q 1066 TRANSISTOR 2SC4617 TL R G3346178R 1- A E2
Q 1067 IC TA31136FNG(EL) G1091605 1- B c2
Q 1067 IC AA32416 G1094857 83- B c2
Q 1068 FET 2SK880GR(TE85R.F) G3808807G 1- B c3
Q 1069 IC LC87F5BP6A-F54P8-E G1094184 1- A F1
Q 1069 IC LC87F5KP6A-F57R5-E G1094387 16- A F1
Q 1070 IC SA7025DK G1093014 1- B c3
Q 1071 TRANSISTOR 2SC4617 TL R G3346178R 1- B c2
Q 1072 IC NJM12902V-TE1 G1093592 1- A B3
Q 1073 IC LM2902PWR G1094009 1- B a1
Q 1074 IC LM2902PWR G1094009 1- B b1
Q 1075 IC LM2902PWR G1094009 1- A F3
Q 1076 IC LM2904PWR G1094010 1- A C1
Q 1077 IC LM2902PWR G1094009 1- A H3
Q 1078 IC CD4066BPWR G1093865 1- B b2
Q 1078 IC NJU4066BV-TE1 G1091873 3- B b2
Q 1079 TRANSISTOR DTC144EE TL G3070075 1- B c1
Q 1080 IC LM2904PWR G1094010 1- B c2
Q 1081 TRANSISTOR DTC144EE TL G3070075 1- B c1
Q 1083 IC LM2902PWR G1094009 1- A G3
Q 1084 TRANSISTOR DTC144EE TL G3070075
1- A B3
Q 1085 IC TC7S08FU(TE85R.F) G1091528 1- A H1
Q 1086 TRANSISTOR UMD5N TR G3070343 1- A H1
Q 1087 TRANSISTOR DTC144EE TL G3070075 1- A E1
Q 1088 FET RTM002P02(TAPE) G3070347 1- A B3
Q 1089 TRANSISTOR DTC144EE TL G3070075 4- B c2
R 1001 CHIP RES. 18 k 1/16W 5% RMC1/16S 183JTH J24189040 1- A C1
R 1001 CHIP RES. 12 k 1/16W 5% RMC1/16S 123JTH J24189038 20- A C1
R 1002 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A C1
R 1003 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A C1
R 1003 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 35- A C1
R 1004 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1005 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B1
R 1006 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B4
R 1007 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B g3
R 1008 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B1
R 1009 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B1
R 1010 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C1
R 1011 CHIP RES. 12 k 1/16W 5% RMC1/16S 123JTH J24189038 1- A B2
R 1012 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A3
R 1013 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A A3
R 1014 CHIP RES. 47 0 1/16W 5% RMC1/16S 471JTH J24189021 1- A C1
R 1015 CHIP RES. 4. 7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- A A2
R 1016 CHIP RES. 4. 7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- A B2
R 1018 CHIP RES. 10 0 1/16W 5% RMC1/16S 101JTH J24189013 1- A B1
R 1019 CHIP RES. 15 0 1/10W 5% RMC1/10T 151J J24205151 1- B g3
R 1020 CHIP RES. 47 0 1/16W 5% RMC1/16S 471JTH J24189021 1- A C1
R 1021 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 1022 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C1
